Page 644 - ISCAR(MILLINGCATALOG 38_2021)

BT MAS-403 BT-FC-SRK CRKS SS BD LPR LBX LB ADJRGA BTED A 0.003 A AT3 Taper 50-52 HRc
LSCWS
4˚
Thermal Shrink Chucks with
G2.5
DCONWS
BT MAS-403 Face Contact
25,000 RPM
U<1.0 gmm
THID
AD Tapered Shanks
BD
Designation
LB
BT30 FC SRK 3X50
0.00
9.93
3.00
30
10.0
0
50.0
0.32
M6
72.00
M12
BT30 FC SRK 4X50 SS DCONWS BTED 15.00 LPR LBX 36.30 ADJRGA LSCWS THID CRKS CDI (1) kg
M12
0
0.46
0.00
12.0
M6
36.30
9.93
4.00
30
50.0
72.00
15.00
BT30 FC SRK 6X50 30 6.00 10.88 16.00 72.00 50.0 36.60 0.00 18.0 M8 M12 0 0.52
BT30 FC SRK 8X50 30 8.00 13.95 20.00 72.00 50.0 43.30 0.00 25.0 M10 M12 0 0.48
BT30 FC SRK12X50 30 12.00 20.03 26.00 72.00 50.0 42.70 10.00 42.0 M10 M12 0 0.53
• Use only inductive heating device for SRKIN holders • For through tool coolant, preset screw must be removed
(1) 1 - Hole for data chip, 0 - Without hole for data chip

Spare Parts
Designation
BT30 FC SRK 3X50 SR M6X10 DIN916
BT30 FC SRK 4X50 SR M6X10 DIN916
BT30 FC SRK 6X50 SR M8X12 DIN916
BT30 FC SRK 8X50 SR M10X10 DIN913
BT30 FC SRK12X50 PRESET M10X18B
