USER GUIDE

SPINJET – A unique, coolant-driven high speed Advantages
compact spindle for small diameter tools. • Reduced machining time - High table speed, thus
faster machining due to high rotation speed
The SPINJET spindles have been developed for use • High efficiency - Up to 65% increased productivity
when high RPM is required for small diameter tools on compared to machining with the original
limited RPM machines. The spindles are for semi-finish machine with low RPM spindle
and finish machining applications such as milling, drilling, • Energy saving - The machine spindle is idle
engraving, chamfering / deburring and fine radial grinding. while the SPINJET is in operation
General View • High precision - Excellent surface quality
due to optimized machining conditions
• Plug & play – Easy installation on existing
machines with no adaptation required
• Extended tool life – As a result of optimal cutting SPINJET COOLENT DRIVEN HSM SPINDLES
conditions and strong jet coolant flow
Features Direct wireless rotation speed display
SPINJET is equipped with an online speed
display system, monitoring the actual cutting
tool rotation speed during machining.
• 2.4 GHz radio frequency transmission
• Direct wireless rotational speed monitoring
in a range of up to 10 meters
• Externally powered display enables reading
all SPINJET systems being used on the machine

Internal Structure

RPM wireless
transmitter
