Page 706 - ISCAR(MILLINGCATALOG 38_2021)

ER32 ER11 DCONXWS
SPINJET COOLENT DRIVEN HSM SPINDLES
G2.5
TJS-GJET-ER32 BD BD_2 BD_3 60,000 RPM
U<1.0 gmm
Coolant Driven High BD_4
Speed Compact Spindles LB
with ER32 Shanks LB_3 LB_2
LB_4
LBX
OAL LPR For ER-SPR collets use "AA" type only
Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX LPR OAL DCONXWS (1) RPMN (2) RPMX (3) CDI (4) kg
TJS GJET ER32 16.00 54.92 63.00 81.00 17.00 24.00 36.44 78.00 95.84 109.00 138.00 7.00 35000 55000 0 1.30
• Minimum coolant pressure 20 bar and flow rate 12 l/min • The spindle provides only external strong coolant jet around the tool
• Battery not supplied • For user guide, see pages 701-703
(1) Maximum tool shank diameter
(2) Minimum RPM
(3) Maximum RPM • (1) Use 4 mm hex key for screw adjustment. • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately)

Spare Parts
Designation
TJS-GJET-ER32 NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY TJS TSD DISPLAY*
* Optional, should be ordered separately

SS BD_4 ER11 DCONXWS G2.5
TJS-GJET-BT BD BD_2 BD_3 60,000 RPM
U<1.0 gmm
Coolant Driven High
Speed Compact Spindles LB
LB_2
with BT Shanks LB_3
LB_4
LBX
LPR
OAL For ER-SPR collets use "AA" type only
Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX SS LF LPR DCONXWS (1) OAL RPMN (2) RPMX (3) CDI (4) kg
TJS GJET BT30 16.00 54.25 63.00 81.00 17.00 24.58 36.24 77.84 109.00 30 124.00 141.00 7.00 189.00 35000 55000 0 1.60
TJS GJET BT40 16.00 54.25 63.00 81.00 17.00 24.58 36.44 77.84 97.04 40 107.00 124.00 7.00 189.00 35000 55000 0 1.80
• Minimum coolant pressure 20 bar and flow rate 12 l/min • The spindle provides only external strong coolant jet around the tool
• Battery not supplied • For user guide, see pages 701-703
(1) Maximum tool shank diameter
(2) Minimum RPM
(3) Maximum RPM • (1) Use 4 mm hex key for screw adjustment. • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately)

Spare Parts
Designation
TJS-GJET-BT NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY TJS TSD DISPLAY*
* Optional, should be ordered separately

BD_4 ER11 DCONXWS G2.5
TJS-GJET-HSK A63 DCONMS BD BD_2 BD_3 60,000 RPM
U<1.0 gmm
Coolant Driven High
LB
Speed Compact Spindles LB_2
with HSK Shanks LB_3
LB_4
LBX
LPR
OAL For ER-SPR collets use "AA" type only
Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX DCONMS LPR OAL DCONXWS (1) RPMN (2) RPMX (3) CDI (4) kg
TJS GJET HSK A63 16.00 54.25 63.00 81.00 17.00 24.58 36.24 77.84 115.00 63.00 141.00 173.00 7.00 35000 55000 0 1.80
• Minimum coolant pressure 20 bar and flow rate 12 l/min • The spindle provides only external strong coolant jet around the tool
• Battery not supplied • For user guide, see pages 701-703
(1) Maximum tool shank diameter
(2) Minimum RPM
(3) Maximum RPM • (1) Use 4 mm hex key for screw adjustment. • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately)

Spare Parts

Designation
TJS-GJET-HSK A63 NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY TJS TSD DISPLAY*
* Optional, should be ordered separately

704 ISCAR
