P. 704
USER GUIDE
SPINJET COOLENT DRIVEN HSM SPINDLES
A New Solution for Cutting Tool Overhang Clamping type: ER11 collet size
Model: SPINJET-
Operating Data Model: HPC
GREEN LINE
Operating range
+10 mm of coolant 15-70 20 - 40
+15 mm pressure [bar]
NUT ER11 GHS
Operating range
ER11 SRK ...10 of coolant flow 10-22 10-20
thermal collet ER11 SRK ...25 rate [l/min]
thermal collet
NUT ER11 GHS Rotational spindle 20,000-45,000 35000- 55000
collet ER11 SPR NUT ER11 GHS speed [rpm]*
Built in ER32 Collet Chuck Featuring high
precision and low runout, suitable for various Optimum cutting Drilling: 0.5 - 3.0 Drilling: 0.5 - 4
standard toolholders with ER32 taper. tool diameter [mm] Milling: 1.0 - 4.0 Milling: 1 - 3.5
Maximum
tool shank 7 7
diameter [mm]
Table 1. – General operating parameters
SPINJET-HPC LINE Spindle Applications
Drilling
SPINJET-HPC ER32 LINE - Adaptation Options
BT DIN69871 CAT40 HSK A 63 C# ST
Thread Milling
Milling
Engraving &
Chamfering
MM ER11 T04/T05 ER11 SRK ER11 SPR
ER11 SRK
Grinding
702 ISCAR
