Page 156 - ISCAR(TURNING-CATALOG-42-2022)

ISOTURN INSERTS CNMM-H5P 25.79 25.40 Dimensions 9.52 RE 2.40 80° Tough 1 Hard Recommended Machining Data
95 º
95 º
75 º
95 º
Single-Sided 80° Rhombic
Insert with a Strong Cutting
IC
Edge for Extra Rough Turning
L
S

IC8250
IC8150
f
ap
Designation
(mm)
IC
RE
S
L
(mm/rev)
•
•
CNMM 250924-H5P
0.55-1.50
5.00-15.00
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: PCLNR/L (20)

75° 95 º
CNMM-NR 80° 95 º 95 º
Single-Sided 80° Rhombic Inserts
for Rough Turning Applications IC 75 º
RE L S
Dimensions Tough 1 Hard Recommended Machining Data
IC8150 IC907 ap f
Designation L IC S RE (mm) (mm/rev)
CNMM 190616-NR 19.03 19.05 6.35 1.60 • • 2.00-10.00 0.40-1.00
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: DCBNR/L (26) • DCLNR/L (25) • MCLNR/L (21) • PCBNR/L (22) • PCLNR/L (20)

IC A-A 15°

XNMG-F3P A S 93 º MAX
Double-Sided 70° Rhombic
Inserts for Semi-Finishing
and Finishing Applications 70
RE A
L

Dimensions Tough 1 Hard Recommended Machining Data

IC830 IC8250 IC8150 IC807 ap f
Designation L IC S RE (mm) (mm/rev)
XNMG 090404-F3P 10.14 9.53 4.76 0.40 • • • • 0.50-3.50 0.07-0.25
XNMG 090408-F3P 10.14 9.53 4.76 0.80 • • • • 0.90-3.50 0.08-0.25
XNMG 120404-F3P 13.52 12.70 4.76 0.40 • • • • 0.50-3.50 0.07-0.25
XNMG 120408-F3P 13.52 12.70 4.76 0.80 • • • • 0.90-3.50 0.08-0.25
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: DXJNR/L-X-JHP-MC (27)

IC A-A 15°

XNMG-M3P A S 93 º MAX
Double-Sided 70° Rhombic
Inserts for Medium Machining
Conditions on Steel 70

RE A
L
Dimensions Tough 1 Hard Recommended Machining Data

IC830 IC8250 IC8150 IC807 ap f
Designation L IC S RE (mm) (mm/rev)
XNMG 090404-M3P 10.14 9.53 4.76 0.40 • • • • 0.50-3.50 0.07-0.25
XNMG 090408-M3P 10.14 9.53 4.76 0.80 • • • • 0.90-3.50 0.08-0.25
XNMG 120404-M3P 13.52 12.70 4.76 0.40 • • • • 0.50-3.50 0.07-0.25
XNMG 120408-M3P 13.52 12.70 4.76 0.80 • • • 0.90-3.50 0.08-0.25
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: DXJNR/L-X-JHP-MC (27)
154 ISCAR
