Page 226 - ISCAR(TURNING-CATALOG-42-2022)

ISOTURN INSERTS TPGX (PCD) Dimensions IC RE 60° LE 11° D1 S 7° Recommended Machining Data
91 º
Triangular Inserts with PCD
Single Top Corner Brazed Tip,
11° Clearance and Positive Rake
Angle for Finishing Aluminum
L

f
ap
RE
IC
S
L
D1
Designation
(mm)
9.52
0.05-0.30
TPGX 090202
3.0
•
9.52
5.56
2.50
0.10-3.00
0.05-0.30
2.38
0.40
3.0
TPGX 090204
•
6.35
0.05-0.30
0.20
3.4
3.50
3.18
TPGX 110302
0.10-3.00
•
3.18
0.10-3.00
6.35
TPGX 110304 11.00 5.56 2.38 0.20 LE 2.50 • ID5 0.10-3.00 (mm/rev)
0.05-0.30
3.50
0.40
11.00
3.8
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A/E-STFPR-X (117) • MG STFPR-X (117)

WNGA-M3 (CBN) 80º Typ. x 3 95 º 95° 95°
Multi-Cornered CBN Inserts for L
Machining Hardened Steel
LE
RE
IC S
Dimensions Recommended Machining Data
f
ap
Designation L IC S RE LE IB20H (mm) (mm/rev)
WNGA 080408-M3 8.70 12.70 4.76 0.80 2.2 • 0.05-0.50 0.05-0.20
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A/S-MWLNR/L-W (103) • A/S-PWLNR/L (104) • C#-MULNR/L-MW (16) • C#-PWLNR/L-08-JHP (9) • DWLNR/L (10)
• HSK A63WH-MULNR-J12MWX2 (17) • HSK A63WH-MULNR/L-MW (16) • HSK A63WH-MUMNN-MW (17) • MULNR/L-12MW (15) • MWLNR/L-W (18)
• PWLNR/L (8) • PWLNR/L-08-JHP (9) • PWLNR/L-X (11) • PWLNR/L-X-JHP (12) • PWLNR/L-X-JHP-MC (13) • S-DWLNR/L (99) • S-MULNR-MW (105)
• DWLNR/L-JHP-MC (10)

80º
WNGA-MC/M6 (CBN) Typ. x 6 95 º 95°
Multi-Cornered CBN Inserts for IC L 95°
Machining Hardened Steel
LE
RE
S
Dimensions Tough 1 Hard Recommended Machining Data
f
ap
Designation L IC S RE LE IB55 IB10HC (mm) (mm/rev)
WNGA 080404T-MC 8.70 12.70 4.76 0.40 3.1 • 0.05-0.50 0.05-0.20
WNGA 080408-M6 8.70 12.70 4.76 0.80 2.2 • 0.05-0.50 0.05-0.20
WNGA 080408T-MC 8.70 12.70 4.76 0.80 3.1 • 0.05-0.50 0.05-0.20
WNGA 080412T-MC 8.70 12.70 4.76 1.20 3.1 • 0.05-0.50 0.05-0.20
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A/S-MWLNR/L-W (103) • A/S-PWLNR/L (104) • C#-MULNR/L-MW (16) • C#-PWLNR/L-08-JHP (9) • DWLNR/L (10)
• HSK A63WH-MULNR-J12MWX2 (17) • HSK A63WH-MULNR/L-MW (16) • HSK A63WH-MUMNN-MW (17) • MULNR/L-12MW (15) • MWLNR/L-W (18)
• PWLNR/L (8) • PWLNR/L-08-JHP (9) • PWLNR/L-X (11) • PWLNR/L-X-JHP (12) • PWLNR/L-X-JHP-MC (13) • S-DWLNR/L (99) • S-MULNR-MW (105)
• DWLNR/L-JHP-MC (10)

224 ISCAR
