GROOVE-TURN GIPA/GIDA 8 (full radius) Dimensions GIDA 80-40CB 10° ±0.025 CW 7° RE Tough 1 Hard Recommended Machining Data
30 Ref.
Precision Double-Ended
6.4
Inserts with Polished Top Rake
GIDA 80-40
for Machining Aluminum
BW
GIPA 8.00-4.00

f turn
f groove
ap
CW
(mm)
RE
Designation
GIDA 80-40 8.00 4.00 CWTOL (2) RETOL (3) BW • IC20 • IC4 ID5 0.00-4.00 (mm/rev) (mm/rev)
0.24-0.67
0.02
0.050
0.14-0.38
5.60
GIDA 80-40-D 8.00 4.00 0.02 0.050 5.60 • 0.00-4.00 0.24-0.67 0.14-0.38
GIDA 80-40CB-D (1) 8.00 4.00 0.02 0.050 5.60 • 0.00-4.00 0.24-0.67 0.14-0.38
GIDA 80-40YZ 8.00 4.00 0.02 0.050 5.60 • • 0.00-4.00 0.24-0.67 0.14-0.38
GIDA 80-40YZ-D 8.00 4.00 0.02 0.050 5.60 • 0.00-4.00 0.35-0.96 0.18-0.48
GIPA 8.00-4.00 8.00 4.00 0.02 0.050 6.00 • 0.00-4.00 0.24-0.67 0.14-0.38
• ID5 is a single-ended PCD tipped insert • For cutting speed recommendations and user guide, see pages 419-428, 432-436
(1) Should not be clamped on tools with "A" suffix
(2) Cutting width tolerance (+/-)
(3) Corner radius tolerance (+/-)
For tools, see pages: C#-GHDR/L (274) • CGHN-8-10D (287) • GADR/L-8 (286) • GADR/L-JHP (287) • GAFG-R/L-8 (580) • GHDKR/L (446)
• GHDR/L (long pocket) (285) • GHDR/L-8A (445) • GHDR/L-JHP (long pocket) (285) • GHFGR/L-8 (579) • GHIFR/L-A (445) • GHIR/L (W=7.0-8.3) (355)
• GHIUR/L-C-A (15° & 27.5°) Bars (444) • GHIUR/L-UC (444)

±0.025 15.3 Ref

GIP-RX/LX
Precision Double-Ended RE 7°
Inserts for External Grooving BW
Next to a Shoulder WFA
CDX 25°
CW
Recommended
Dimensions Tough 1 Hard Machining Data

IC830 IC808 f groove
Designation CW RE CWTOL (1) RETOL (2) CDX (3) BW WFA (mm/rev)
GIP 0.80-0.00R/LX 0.80 0.00 0.02 0.030 1.60 2.40 1.6 • 0.02-0.04
GIP 1.00-0.00R/LX 1.00 0.00 0.02 0.030 2.00 2.40 1.6 • 0.02-0.05
GIP 1.19-0.1RX 1.19 0.10 0.02 0.030 2.00 2.40 1.6 • 0.03-0.05
GIP 1.57-0.15 R/LX 1.57 0.15 0.02 0.030 2.70 2.40 1.7 • 0.04-0.06
GIP 1.57-0.79RX 1.57 0.79 0.02 0.030 2.80 2.40 1.7 • 0.04-0.08
GIP 2.00-0.15 R/LX 2.00 0.15 0.02 0.030 3.00 2.40 1.7 • 0.05-0.08
GIP 2.39-0.15 RX 2.39 0.15 0.02 0.030 3.50 2.40 1.7 • 0.05-0.09
GIP 2.39-1.19RX 2.39 1.19 0.02 0.050 3.90 2.40 1.7 • 0.06-0.12
• Toolholder seat needs to be modified according to insert profile to ensure clearance. • For cutting speed recommendations and user guide, see pages 419-428, 432-436
(1) Cutting width tolerance (+/-)
(2) Corner radius tolerance (+/-)
(3) Cutting depth maximum
For tools, see pages: GHMPR/L (273) • GHMR/L (273)
