GROOVE-TURN PCHR/L-24 10.0 10.0 CWN-CWX f2 WF CWN f1 HF (2) CWN-CWX (3) HBH OAL 6.5 CDX (4) H B 120.00 19.5 HBH

Grooving, Parting and
0.50-3.20 2.0
3.21-4.23 2.5
Recessing Holders Carrying
HBL
4.24-5.20 3.0
Inserts with 5 Cutting Edges
CDX
5.21-6.20 3.5
6.21-8.20 4.5
f2
WF=f1+f2
Right-hand shown
f1
CWX
HF
OAL
B
LH
Designation
H
6.50
6.0
3.20
PCHR/L 10-24
10.0
0.50
PCHR/L 12-24
3.20
12.0
12.0
12.0
0.50
19.5
4.0
8.5
6.50
120.00
PCHR/L 16-24
PCHR/L 20-24
20.0
0.50
20.0
19.5
16.5
120.00
6.50
3.20
20.0
6.50
25.0
PCHR/L 25-24
135.00
25.0
0.50
19.5
3.20
21.5
25.0
120.00
21.5
5.20
3.21
6.40
11.5
16.0
PCHR/L 16-24-5 16.0 16.0 16.0 0.50 3.20 12.5 6.50 120.00 19.5 4.0 - - -
16.0
16.0
PCHR/L 20-24-5 20.0 20.0 20.0 3.21 5.20 15.5 6.40 120.00 21.5 -
PCHR/L 25-24-5 25.0 25.0 25.0 3.21 5.20 20.5 6.40 135.00 21.5 -
PCHR/L 25-24-8 (1) 25.0 25.0 25.0 5.21 8.20 18.5 6.50 135.00 19.5 -
• WF=f1+f2 (according to insert width (CW) being used)
(1) Used with special inserts only
(2) Minimum cutting width
(3) Maximum cutting width
(4) For specific information, refer to insert data
For inserts, see pages: PENTA 24-BSPT (674) • PENTA 24-ISO (657) • PENTA 24-MT (646) • PENTA 24-NPT (670) • PENTA 24-UN (664)
• PENTA 24-W (668) • PENTA 24-WT (641) • PENTA 24N-C (320) • PENTA 24N-C (full radius) (321) • PENTA 24N-J (319) • PENTA 24N-J (full radius) (320)
• PENTA 24N-PF (full radius) (322) • PENTA 24N-PF/P (321) • PENTA 24N-Z (322) • PENTA 24R-C (531) • PENTA 24R-P (534) • PENTA 24R/L-J (530)
• PENTA 24R/L-Z (533)

Spare Parts
Designation
PCHL 10-24 SR 16-212-01397L
PCHR 10-24 SR 16-212-01397
PCHL 12-24 SR 16-212-01397L
PCHR 12-24 SR 16-212-01397
PCHL 16-24 SR 16-212-01397L
PCHR 16-24 SR 16-212-01397
PCHL 20-24 SR 16-212-01397L
PCHR 20-24 SR 16-212-01397
PCHL 25-24 SR 16-212-01397L
PCHR 25-24 SR 16-212-01397
PCHR/L 16-24-5 SR PCHR/L-8-06642 T-15/5
PCHR/L 20-24-5 SR PCHR/L-8-06642 T-15/5
PCHR/L 25-24-5 SR PCHR/L-8-06642 T-15/5
PCHR/L 25-24-8 SR PCHR/L-8-06642 T-15/5
