GROOVE-TURN PCHRS/LS 12.0 12.0 CWN (1) CWX (2) CWN-CWX 19.5 WF HBL OAL HBH OAH OAH 12.0 SR 16-212-01397R/LS T-2010/5
LH
HF
H
Holders Carrying Inserts with
HBH
5 Cutting Edges for Grooving,
HBL
Parting and Recessing
B
Next to High Shoulders
3º Pocket Inclination
Right-hand shown
H
Designation
LH
HF
OAL
B
PCHR/LS 12-24
4.80
120.00
0.80
24.50
21.0
4.0
PCHR/LS 16-24
PCHR/LS 20-24
SR 16-212-01397R/LS
20.0
120.00
4.80
0.80
T-2010/5
20.0
20.0
19.5
25.0
19.5
T-2010/5
4.80
25.0
135.00
SR 16-212-01397R/LS
30.0
25.0
PCHR/LS 25-24
0.80
25.0
(1) Minimum cutting width 16.0 16.0 0.80 4.80 120.00 19.5 - - - - - - 21.0 16.0 SR 16-212-01397R/LS T-2010/5
(2) Maximum cutting width
For inserts, see pages: PENTA 24N-J-RS (323) • PENTA 24N-RS/LS (323)
3°

LH
PCHR/L-27-JHP-MC HH CNT
Tools Carrying Pentagonal HF H Coolant Outlets Bar Max
Wide Inserts for Specially HBH
Tailored Profiles HBL OAL
HBKW
CW B
Right-hand shown
Designation CW H B HF LH HBL HH HBH HBKW OAL CNT
PCHR/L 20-27-10-JHP-MC 10.00 20.0 20.0 20.0 32.0 33.0 17.4 13.0 5.00 103.00 G1/8
PCHR/L 25-27-10-JHP-MC 10.00 25.0 25.0 25.0 32.0 33.0 17.4 8.0 - 118.00 G1/8
PCHR/L 20-27-15-JHP-MC 15.00 20.0 20.0 20.0 32.0 33.0 17.4 13.0 5.00 103.00 G1/8
PCHR/L 25-27-15-JHP-MC 15.00 25.0 25.0 25.0 32.0 33.0 17.4 8.0 - 118.00 G1/8
PCHR/L 20-27-20-JHP-MC 20.00 20.0 20.0 20.0 32.0 33.0 17.4 13.0 5.00 103.00 G1/8
PCHR/L 25-27-20-JHP-MC 20.00 25.0 25.0 25.0 32.0 33.0 17.4 8.0 - 118.00 G1/8
For inserts, see pages: PENTAS 27 blanks (323)

Spare Parts
Designation
PCHR/L 20-27-20-JHP-MC SR M3X6 ISO7380 SS HW 3.0 SR M6X6 DIN913 SR M6X6 DIN913 TL360 PUSH ROD - 40529 HW 4.0 PLG G1/8 TL360 HW 5.0
PCHL 25-27-20-JHP-MC SR M3X6 ISO7380 SS HW 3.0 SR M6X6 DIN913 SR M6X6 DIN913 TL360 PUSH ROD - 40529 HW 4.0 PLG G1/8 TL360 HW 5.0
PCHR 25-27-20-JHP-MC PUSH ROD - 40529 HW 4.0
