GAMF GAMP 50°
LH
TOOLS FOR ALUMINUM WHEELS
SVJCR/L-16-JHP MAX
Screw Lock Tools with Channels HF H 93°
for High Pressure Coolant 4° G 1/8"-28 105°
Carrying 35° Rhombic Inserts 4° Central coolant direction B
with 7° Clearance Angle (8° rotation adjustment) WF
KAPR LF Bar Max

Designation H B HF LF LH WF KAPR (1) GAMP GAMF Insert
SVJCR/L 2525M-16-JHP 25.0 25.0 25.0 150.00 42.0 32.00 93.0 0.0 0.0 VCMT 1604
• For user guide, see pages 78-84
(1) Tool cutting edge angle
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)

Spare Parts

Designation
SVJCR/L 2525M-16-JHP TVC 3-1 SR TC-3 SR 16-236 P CU-V-JHP T-15/5 HW 2.5 T-8/5

70°MAX
SVVCN LH 72.5 º
72.5° Lead Angle Screw Lock HF H
Tools Carrying the 35° Diamond
Inserts with 7° Clearance Angle WF
B
LF

Designation H HF B LF LH WF GAMP GAMF Insert
SVVCN 0808K-11S (1) 8.0 8.0 8.0 125.00 - 4.30 0.0 0.0 VC..1103 SR 14-560 T-8/5
SVVCN 1010K-11S (1) 10.0 10.0 10.0 125.00 - 5.30 0.0 0.0 VC..1103 SR 14-560 T-8/5
SVVCN 1212K-11S (1) 12.0 12.0 12.0 125.00 - 6.30 0.0 0.0 VC..1103 SR 14-560 T-8/5
SVVCN 1616K-11S (1) 16.0 16.0 16.0 125.00 - 8.30 0.0 0.0 VC..1103 SR 14-560 T-8/5
SVVCN 2020K-16 20.0 20.0 20.0 125.00 34.0 10.00 0.0 0.0 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
SVVCN 2525M-16 25.0 25.0 25.0 150.00 38.1 12.50 0.0 0.0 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
(1) For Swiss-type machines
For inserts, see pages: • VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196)
• VCMT-SM (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)

LH 31°
SVXCR/L HF H MAX
112°
112° Lead Angle Screw Lock
Tools Carrying the 35° Diamond
Inserts with 7° Clearance Angle WF B
LF
Right-hand shown

Designation H HF B LF LH WF GAMP GAMF Insert
SVXCR/L 2020K-16 20.0 20.0 20.0 125.00 25.0 25.00 0.0 0.0 VC..1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5
SVXCR/L 2525M-16 25.0 25.0 25.0 150.00 30.0 32.00 0.0 0.0 VC..1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
