Page 710 - ISCAR(TURNING-CATALOG-42-2022)

Tools for External Grooving and Threading Inserts

THREADING Tools for External Grooving (1) WF CDX 3° LF B Right-hand shown
H
FLSR/L
and Threading Inserts

WF
B
Designation
LF
Insert
2.0
3.00
FLSR/L-2020M2
FLSR/L-2020M3
20.0
125.00
3.0
25.00
5.00
FL/IN_-3
FLSR/L-2525M2 SSC 20.0 CDX 25.00 125.00 FL/IN_-2
32.00
150.00
FL/IN_-2
2.0
25.0
3.00
FLSR/L-2525M3 3.0 25.0 5.00 32.00 150.00 FL/IN_-3
(1) Seat size code
For inserts, see pages: 60° PARTIAL PROFILE THREADING FLT (649) • 60° PARTIAL PROFILE THREADING FLT-CB (649) • 60° PARTIAL PROFILE THREADING FLTF (648)
• 60° PARTIAL PROFILE THREADING FLTK (649) • 60° PARTIAL PROFILE THREADING FLTP (650) • ACME THREADING FLA (678) • ACME THREADING FLA-PT-E (679)
• ACME THREADING FLAS (678) • AMERICAN STANDARD BUTTRESS THREADING FLTB-A (688) • AMERICAN STANDARD BUTTRESS THREADING FLTB-B (688)
• API PARTIAL PROFILE THREADING FLD (691) • API ROUND THREADING FLDC-RD-75 (689) • API ROUND THREADING FLDC-RD-75-CB (689)
• NPT THREADING FLDC-V-75 (671) • STUB ACME THREADING FLAS-PT-E (676) • UN THREADING FLTC-E (665) • UNJ THREADING FLJ (681)
• UNJ THREADING FLJF (682) • UNJ THREADING FLJK (682) • UNJ THREADING FLJP (682)

HF H
FLASR/L CDX LF
External Tools for Grooving
and Threading for Swiss-type WF B
Machines 3˚
Designation SSC (1) H HF B CDX WF LF Insert
FLASR/L-1010M2 2.0 10.0 10.0 10.0 3.51 10.00 150.00 FL/IN_-2
FLASR/L-1212M2 2.0 12.0 12.0 12.0 3.51 12.00 150.00 FL/IN_-2
FLASR-1616M2 2.0 16.0 16.0 16.0 3.51 16.00 150.00 FL/IN_-2
FLASR/L-1616M3 3.0 16.0 16.0 16.0 5.31 16.00 125.00 FL/IN_-3
(1) Seat size code
For inserts, see pages: 60° PARTIAL PROFILE THREADING FLT (649) • 60° PARTIAL PROFILE THREADING FLT-CB (649) • 60° PARTIAL PROFILE THREADING FLTF (648)
• 60° PARTIAL PROFILE THREADING FLTK (649) • 60° PARTIAL PROFILE THREADING FLTP (650) • ACME THREADING FLA (678) • ACME THREADING FLA-PT-E (679)
• ACME THREADING FLAS (678) • AMERICAN STANDARD BUTTRESS THREADING FLTB-A (688) • AMERICAN STANDARD BUTTRESS THREADING FLTB-B (688)
• API PARTIAL PROFILE THREADING FLD (691) • API ROUND THREADING FLDC-RD-75 (689) • API ROUND THREADING FLDC-RD-75-CB (689)
• NPT THREADING FLDC-V-75 (671) • STUB ACME THREADING FLAS-PT-E (676) • UN THREADING FLTC-E (665) • UNJ THREADING FLJ (681)
• UNJ THREADING FLJF (682) • UNJ THREADING FLJK (682) • UNJ THREADING FLJP (682)
