INTRODUCTION
      MODULAR-GRIP ADAPTATIONS


          Modular-Grip Adaptations




              Modular Adaptation Systems for                    Available adapters for the following specific machines:
              Turning Lathes and Multi-Spindle                •  STAR
              Machine Tools Carrying ISCAR’s                  •  DOOSAN / HAAS
              MODULAR-GRIP Adapters Featuring                 •  MAZAK
                                                              •  DMG MORI
              Directed Internal Coolant Channels              •  BIGLIA / EUROTECH
                                                              •  MIYANO
              Product Features
            •  The unique combination of a rigid tool and     •  NAKAMURA-TOME
              efficient coolant improves the insert’s tool    •  INDEX ABC
                                                              •  TRAUB
              life, surface finish and part straightness
            •  Designed for high-pressure coolant up to 150 Bar and also   •  OKUMA
                                                              •  TSUGAMI
              very efficient when using low coolant pressure of 7-10 Bar
            •  No coolant tubes involved, which means           Multi-Spindle machine tools
              no obstruction for chip evacuation              •  INDEX CNC
            •  Each adapter can carry several types           •  Schütte
              of MODULAR-GRIP blades                          •  Göltenbodt
            •  Excellent tool location repeatability after
              blade replacement for fast setup
            •  Easy and user-friendly mounting



























































          All trademarks and logos are the property of their respective companies
