Page 755 - ISCAR(TURNING-CATALOG-42-2022)

· USER GUIDE

Adapters with Internal Coolant

Modular-Grip Adapters with Directed Internal Coolant
Coolant Connection from Coolant / lubrication
Extremely Stable Vario System
the Holder into the Adapter in the cutting zone

Features ø 22 ø 32 TAGPAD-JHP HGPAD-JHP NON-ROTATING TOOL HOLDERS

ø 42 ø 52
DGPAD-JHP CGPAD-JHP
• Adapters designed for • Chips do not accumulate in • Increased tool life • Different cutting
common bar diameters the work space (no coolant • Improved process safety systems can be used.
• Reduced vibration due • No tube/hoses to • Better chip control Grooving and turn-
tube/hose required)
to strong adapter body
groove operations can
Benefits • Strong clamping force be removed in case be performed with
of tool breakage
by screw clamping
the same holder
• Free work space • Extremely flexible
