P. 101
DIN 371
PM
M ISO DIN 13 DIN 376
S320VS«4 S320VS«4 S420VS«4
S
S320VS-4 VS 13 15 16 22 23 24
52
S420VS-4 VS 13 15 16 22 23 24
52
B B B
a
d 2
4 x P 4 x P 4 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a ID ID ID
M mm mm mm mm mm mm
3 0.5 56 12 18 3.5 2.7 3 2.5 l 111596 165318
4 0.7 63 14 21 4.5 3.4 3 3.3 l 111597 165319
5 0.8 70 15 25 6 4.9 3 4.2 l 111598 165320
6 1 80 17 30 6 4.9 3 5 l 111599 165321
8 1.25 90 20 35 8 6.2 3 6.8 l 111600 165322
10 1.5 100 22 39 10 8 3 8.5 l 111601 165323
12 1.75 110 24 9 7 4 10.2 l 111602
16 2 110 30 12 9 4 14 l 111603
20 2.5 140 36 16 12 4 17.5 l 111604
= 6.7
