Page 102 - DC_SWISS(Catalogue_TM_ES-EN)

~ DIN 371
PM
M ISO DIN 13 DIN 376

S360VS«3 S460VS«3 SA390«3 SA390«3
S

S360VS-3 VS 13 15 16 22 23 24
R35 52

S460VS-3 VS 13 15 16 22 23 24
R35 52

< 2 x D < 2 x D < 1.5 x D < 1.5 x D

SA390-3 16 53
R10
< 1.5 x D < 1.5 x D

C C C C
a
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a ID ID
M mm mm mm mm mm mm
3 0.5 56 5.5 18 3.5 2.7 3 2.5 l 111513
4 0.7 63 7.5 21 4.5 3.4 3 3.3 l 111514
5 0.8 70 9 25 6 4.9 3 4.2 l 111515
6 1 80 11 30 6 4.9 3 5 l 111516
8 1.25 90 12.5 35 8 6.2 3 6.8 l 111517
10 1.5 100 14 39 10 8 3 8.5 l 111518
12 1.75 110 14 9 7 4 10.2 l 111519
14 2 110 14 11 9 4 12 148171
16 2 110 18 12 9 4 14 l 111520
20 2.5 140 24 16 12 4 17.5 l 111521
24 3 160 27 18 14.5 4 21 l 111606

Ø d 1 P l 1 l 2 d 2 a ID ID
M mm mm mm mm mm
4 0.7 63 14 4.5 3.4 3 3.3 l 149673 l 149674
5 0.8 70 15 6 4.9 3 4.2 l 149693 l 149694
6 1 80 20 6 4.9 3 5 l 149707 l 149708
8 1.25 90 25 8 6.2 3  6.8 l 149736 l 149737
10 1.5 100 30 10 8 3 8.5 149754 l 149755
12 1.75 110 35 12 9 4 10.2 l 149775
14 2 110 40 16 12 4 12 149792


