P. 148
Uniquement pour taraudage synchrone
Nur für Sychronbearbeitung ~ DIN 371 (d2 h6)
Only for rigid tapping PM
MF ISO DIN 13 SYNCHRO Solo per maschiatura sincrona ~ DIN 376 (d2 h6)
Solo para roscado sincronizado
Только для ridgid tapping
RT S RTS320VS 4 RTS420VS 4 RTS362VS 3 RTS462VS 3
Rigid Tapping Sy nc hro
11 12 13 14
RTS320VS-4 VS 15 21 31 32
51 61 63
72 73 74 81
RTS420VS-4 VS 82 83 91 92
94
11 12 13 14
RTS362VS-3 VS 15 21 31 32
R40
51 61 63
72 73 74 81 < 2.5 x D < 2.5 x D
RTS462VS-3 VS 82 83 91 92
R40 94
B B C C
a
d 2
4 x P 4 x P 2.5 x P 2.5 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d h6 a ID ID
2
MF mm mm mm mm mm mm
8 1 90 12.5 35 8 6.2 3 7 l 150615
10 1 100 14 39 10 8 3 9 l 150630
12 1.5 110 14 * 10 * 8 3 10.5 l 150640
14 1.5 110 14 * 12 * 9 3 12.5 l 150655
16 1.5 110 18 12 9 3 14.5 l 150665
* Norme DC / * DC Norm/ * Norma DC
Ø d 1 P l 1 l 2 l 3 d h6 a ID ID
2
MF mm mm mm mm mm mm
8 1 90 12.5 35 8 6.2 3 7 l 150617
10 1 100 14 39 10 8 3 9 l 150632
12 1.5 110 14 * 10 * 8 3 10.5 l 151862
14 1.5 110 14 * 12 * 9 3 12.5 l 151869
16 1.5 110 18 12 9 3 14.5 l 151871
* Norme DC / * DC Norm/ * Norma DC
sur demande
auf Anfrage
on request
su richiesta
> Ø 6 mm sobre pedido
по запросу
