UNF ASME B1.1 PM DIN 374
DIN 371

H320 4 H420 4 H320TC 4 H420TC-4
H

H320-4 15 16 62 82

H420-4 15 16 62 82

NEW
NEW
H320TC-4 TiCN 15 16 24 31 82 83 NEW NEW
92 93

H420TC-4 TiCN 15 16 24 31 82 83
92 93

B B B B
a
d 2
4 x P 4 x P 4 x P 4 x P
d 1
l
2
l
3 l P
1
Ø’’ d 1 P d 1 l 1 l 2 l 3 d 2 a ID ID ID ID
UNF TPI mm mm mm mm mm mm
10 32 4.82 70 15 25 6 4.9 3 4.05 l 101228 l 196060
1/4 28 6.35 80 17 30 7 5.5 3 5.5 l 101227 l 142613
5/16 24 7.93 90 20 35 8 6.2 3 6.9 l 105139 l 196061
3/8 24 9.52 100 22 39 10 8 3 8.5 l 101229 l 196062
7/16 20 11.11 100 19 8 6.2 3 9.8 l 147253 l 196063
1/2 20 12.7 100 24 9 7 4 11.4 l 101291 l 196064
5/8 18 15.87 100 26 12 9 4 14.5 l 101293 l 196065
3/4 16 19.05 125 33 14 11 4 17.5 l 101292 l 196066
