DIN 5156 (Rp)
HSSE
Rp, Rc DIN EN 10226 DC (Rc)

N420 3 N410-3

N

63 72 73 74
N420-3
81 91

N410-3 31 74
1:16

C
a
d 2 2.5 x P 2 x P
d 1
l
2
l P
1
Ø’’ d P d l l d a
1
2
1
Rp 1 TPI mm mm mm mm 2 mm ID
1/8 28 9.72 90 22 7 5.5 3 8.6 l 104911
1/4 19 13.15 100 20 11 9 3 11.5 l 104912
3/8 19 16.66 100 20 12 9 3 15 l 104913
1/2 14 20.95 125 22 16 12 4 18.5 l 104914
3/4 14 26.44 140 28 20 16 4 24 l 104915
1 11 33.24 160 32 25 20 4 30.25 l 104916

Ø’’ d 1 P d 1 l 1 l 2 d 2 a ID
Rc TPI mm mm mm mm mm
1/8 28 9.72 71 13 8 6.2 5 l 104917
1/4 19 13.15 80 20 11 9 5 l 104918
3/8 19 16.66 90 20 12 9 5 l 104919
1/2 14 20.95 100 26 16 12 5 l 104920
3/4 14 26.44 110 26 20 16 5 l 104921
1 11 33.24 125 32 25 20 5 l 104922

Vc (m/min) Ø d1 - Guide Line
Rc 1/16’’ - 1/4’’ 3/8’’ - 1/2’’ 3/4’’ - 1’’ 1.1/4’’ - 2’’

31 74 10 8 7 5
62 18 15 13 10
