≤ Ø 16 > Ø 16
PM HSSE DIN 5156
G DIN EN ISO 228 (BSP) CLASSIC SYNCHRO
QTAP Q460VS-3 Q463VS-3
11 12 13 14
15 21 22 23
Q460VS-3 VS
R40 24 31 32 51
52 61 62 63
NEW
NEW
Q463VS-3 VS 71 72 73 NEW NEW
R40 74 81 82 83
91 92 94 < 2.5 x D < 2.5 x D
a C C
d 2
2.5 x P 2.5 x P
d 1
l 2
l P
1
Ø’’ d 1 P d 1 l 1 l 2 d 2 a ID ID
G TPI mm mm mm mm mm
1/8 28 9.72 90 14 7 5.5 3 8.75 l 196316 l 197649
1/4 19 13.15 100 14 11 9 3 11.6 l 196317 l 197650
3/8 19 16.66 100 14 12 9 4 15.2 l 196318 l 197651
1/2 14 20.95 125 20 16 12 4 18.9 l 196319 l 197652
