P. 212
PM ~ DIN 376 (d2 h6)
G DIN EN ISO 228 (BSP)
Z Z470VS 3
S
Z470VS-3 VS 14 15 21 22 23
R45 CLASSIC 24 51 61 94
Z470VS-3 VS 13 14 15 21 22
R45 SYNCHRO 23 24 51 52
< 3 x D
a C
d 2
2.5 x P
d 1
l 2
l P
1
Ø’’ d 1 P d 1 l 1 l 2 d h6 a ID
2
G TPI mm mm mm mm mm
1/8 28 9.72 100 14 * 8 * 6.2 3 8.75 l 165198
1/4 19 13.15 110 14 * 12 * 9 4 11.6 l 165199
3/8 19 16.66 110 18 12 9 4 15.2 l 165200
1/2 14 20.95 125 20 16 12 4 18.9 l 165201
* Norme DC / * DC Norm/ * Norma DC
