Page 289 - DC_SWISS(Catalogue_TM_ES-EN)

N Z
HSS HSSE DC
M ISO DIN 13

N5220 11 12 N5220 N5220 Z5220
≥ Ø 3

N5220 11 12
≥ Ø 3

Z5220 NI 13 14 21
≥ Ø 2

1.75 x P 1.75 x P 2 x P
1.5 x D 1 1.5 x D 1 1.5 x D 1

P

Ø d 1 P d 2 l 1 TK ID ID 6g ID
M mm mm mm mm  6g   6e  - mm
1.4 0.3 16 2.6 4 12.2 1.36 l 104346
1.6 0.35 16 2.6 4 12.2 1.54 l 104347
2 0.4 16 3.5 4 12.2 1.93 l 104367
2.3 0.4 16 3.5 4 12.2 2.23 l 104369
2.5 0.45 16 3.5 4 12.2 2.43 l 104371 l 104803
2.6 0.45 16 3.5 4 12.2 2.53 l 104372
3 0.5 16 3.5 4 12.2 2.92 2.9 l 104375 l 104374 0.030 l 104804
3.5 0.6 16 4 4 12.2 3.41 l 104376
4 0.7 16 5 4 12.2 3.91 3.87 l 104380 l 104379 0.035 l 104805
5 0.8 20 7 4 15 4.9 4.87 l 104384 l 104383 0.035 l 104806
6 1 20 7 4 15 5.88 5.85 l 104388 l 104387 0.035 l 104807
8 1.25 25 9 4 19 7.87 7.83 l 104397 l 104396 0.035 l 104808
10 1.5 30 11 6 23 9.85 9.82 l 104354 l 104353 0.035
12 1.75 30 11 6 23 11.83 l 104358
