PM DC – DIN 371
SF NIHS 06-10 Fine Thread CLASSIC SYNCHRO

FA FA80VS FA83VS

FA80VS VS 11 12 13 14 15
21 22 23 24 51
61 63 71 72

FA83VS VS 73 91 92 94

< 2.5 x D < 2.5 x D

C
1.5 x P 2.5 x P
d 2 a
d 1
l
2 NIHS NIHS
l
1 P
Ø d 1 P l 1 l 2 d 2 a ID ID
SF mm mm mm mm mm
1.4 0.2 40 4.2 2.5 ∆ 1.31 l 176180 l 193793
1.6 0.2 40 4.8 2.5 ∆ 1.51 l 193757 l 193794
1.8 0.2 40 5.4 2.5 ∆ 1.71 l 193758 l 193795
2 0.2 45 6 2.8 2.1 ∆ 1.91 l 193759 l 193796
2.2 0.2 45 6.6 2.8 2.1 ∆ 2.11 l 193760 l 193797
2.2 0.25 45 6.6 2.8 2.1 ∆ 2.08 l 193761 l 193798
2.5 0.2 50 7.5 2.8 2.1 ∆ 2.41 l 193762 l 193799
2.5 0.25 50 7.5 2.8 2.1 ∆ 2.38 l 193763 l 193800
∆
Tol. = +0/0.02 mm
