VHM DC
UNC ASME B1.1 CLASSIC SYNCHRO CAR
CFA CFA80VS CFA83VS
CFA80VS VS
63 91 92 94
CFA83VS VS
< 2.5 x D < 2.5 x D
C
1.5 x P 2.5 x P
d 2
d 1
l 2
l P
1
Ø d 1 P d 1 l 1 l 2 d h5 ID ID
2
UNC TPI mm mm mm mm
1 64 1.85 32 5.5 2 ∆ 1.65 l 193596 l 193625
2 56 2.18 39 8.6 3 ∆ 2 l 193597 l 193626
3 48 2.51 39 10 3 ∆ 2.25 l 193598 l 193627
∆
Tol. = +0/0.02 mm
