P. 375
UNF ASME B1.1 CLASSIC SYNCHRO VHM DC
CAR
CFA CFA80VS CFA83VS
CFA80VS VS
63 91 92 94
CFA83VS VS
< 2.5 x D < 2.5 x D
C
1.5 x P 2.5 x P
d 2
d 1
l 2
l P
1
Ø d 1 P d 1 l 1 l 2 d h5 ID ID
2
UNF TPI mm mm mm mm
0 80 1.52 32 4.5 2 ∆ 1.4 l 193599 l 193628
1 72 1.85 32 5.5 2 ∆ 1.7 l 193600 l 193629
2 64 2.18 39 8.6 3 ∆ 2 l 193601 l 193630
3 56 2.51 39 10 3 ∆ 2.3 l 193602 l 193631
∆
Tol. = +0/0.02 mm
