ISO DIN 14 / ISO DIN 13 VHM
M DC SWISS NI589 / ISO 1502 CAR

RN05-1 GO RN15-1 GO RN05-1 GO RN15-1 GO

d 2

l
1

l
2

d 1

P

Ø d 1 P l 1 l GO d 2 ID ID ID ID
2
M mm mm mm mm
0.3 0.08 24 0.61 6 l 192884 l 192892
0.35 0.09 24 0.71 6 l 192885 l 192893
0.4 0.1 24 0.8 6 l 192886 l 192894
0.5 0.125 24 1 6 l 192887 l 192895
0.6 0.15 24 1.2 6 l 192888 l 192896
0.7 0.175 24 1.4 6 l 192889 l 192897
0.8 0.2 24 1.6 6 l 192890 l 192898
0.9 0.225 24 1.8 6 l 192891 l 192899
1 0.25 24 2 6 l 191499 l 191508
1.2 0.25 24 2.3 6 l 191500 l 191509
1.4 0.3 24 2.7 6 l 191501 l 191510

Ø d 1 P l 1 l GO d 2 ID ID
2
M mm mm mm mm
1.6 0.35 24 3.1 6 l 191517 l 191535
1.8 0.35 24 3.4 6 l 191518 l 191536
2 0.4 24 3.8 6 l 191519 l 191537
2.3 0.4 24 4.25 6 l 191520 l 191538
2.5 0.45 24 4.65 6 l 191521 l 191539
2.6 0.45 24 4.8 6 l 191522 l 191540

SCS certificate included.
