Application Material [mm] z [m/min] [mm] [mm] [mm] [min ] -1 [mm/min] [cm /min]
3
Nickel-based alloys 6.00 4 35 0.020 10.800 2.400 1855 148 3.8
annealed 8.00 4 35 0.025 14.400 3.200 1395 140 6.4
Rm <1000 N/mm² 10.00 4 35 0.030 18.000 4.000 1115 134 9.6
[Inconel 718] 12.00 4 35 0.040 21.600 4.800 930 149 15.4
16.00 4 35 0.045 28.800 6.400 695 125 23.1
20.00 4 35 0.055 36.000 8.000 555 122 35.2
Nickel-based alloys 6.00 4 25 0.015 10.800 2.400 1325 80 2.1
precipitation hardened 8.00 4 25 0.020 14.400 3.200 995 80 3.7
Rm > 1000 N/mm² 10.00 4 25 0.025 18.000 4.000 795 80 5.7
[Inconel 718] 12.00 4 25 0.030 21.600 4.800 665 80 8.3
16.00 4 25 0.035 28.800 6.400 495 69 12.8
20.00 4 25 0.045 36.000 8.000 400 72 20.7
Manganese steel 6.00 4 40 0.020 10.800 2.400 2120 170 4.4
Mn >5% 8.00 4 40 0.025 14.400 3.200 1590 159 7.3
[1.3964 / Nitronic] 10.00 4 40 0.030 18.000 4.000 1275 153 11.0
[1.3401 / X120Mn12] 12.00 4 40 0.040 21.600 4.800 1060 170 17.6
16.00 4 40 0.045 28.800 6.400 795 143 26.4
20.00 4 40 0.055 36.000 8.000 635 140 40.2
Inox difficult 6.00 4 50 0.030 10.800 2.400 2655 319 8.3
[Cr-Ni-Mo++/1.4529] 8.00 4 50 0.040 14.400 3.200 1990 318 14.7
Heat resistant steel 10.00 4 50 0.050 18.000 4.000 1590 318 22.9
[1.4841] 12.00 4 50 0.060 21.600 4.800 1325 318 33.0
16.00 4 50 0.065 28.800 6.400 995 259 47.7
20.00 4 50 0.080 36.000 8.000 795 254 73.3

PM high-speed steel 6.00 4 80 0.020 10.800 2.400 4245 340 8.8
annealed 8.00 4 80 0.025 14.400 3.200 3185 319 14.7
[Böhler S390] 10.00 4 80 0.030 18.000 4.000 2545 305 22.0
[ASP 2023] 12.00 4 80 0.040 21.600 4.800 2120 339 35.2
16.00 4 80 0.045 28.800 6.400 1590 286 52.8
20.00 4 80 0.055 36.000 8.000 1275 281 80.8

Titanium alloys 6.00 4 70 0.020 10.800 2.400 3715 297 7.7
> 300 HB 8.00 4 70 0.025 14.400 3.200 2785 279 12.8
[Ti6Al4V] 10.00 4 70 0.030 18.000 4.000 2230 268 19.3
12.00 4 70 0.035 21.600 4.800 1855 260 26.9
16.00 4 70 0.040 28.800 6.400 1395 223 41.1
20.00 4 70 0.050 36.000 8.000 1115 223 64.2

Nickel-based alloys 6.00 4 25 0.015 7.200 6.000 1325 80 3.4
annealed 8.00 4 25 0.020 9.600 8.000 995 80 6.1
Rm <1000 N/mm² 10.00 4 25 0.025 12.000 10.000 795 80 9.5
[Inconel 718] 12.00 4 25 0.030 14.400 12.000 665 80 13.8
16.00 4 25 0.035 19.200 16.000 495 69 21.3
20.00 4 25 0.045 24.000 20.000 400 72 34.6

Nickel-based alloys 6.00 4 20 0.010 7.200 6.000 1060 42 1.8
precipitation hardened 8.00 4 20 0.015 9.600 8.000 795 48 3.7
Rm > 1000 N/mm² 10.00 4 20 0.020 12.000 10.000 635 51 6.1
[Inconel 718] 12.00 4 20 0.025 14.400 12.000 530 53 9.2
16.00 4 20 0.030 19.200 16.000 400 48 14.7
20.00 4 20 0.035 24.000 20.000 320 45 21.5
