Page 292 - 21-036 APPLITEC catalogue.indb
P. 292
a e
n
v f
a p
d 1
v c
f z
Q
Application Material [mm] z [m/min] [mm] [mm] [mm] [min ] -1 [mm/min] [mm /min]
3
Steel 2.10 2 180 0.038 1.680 0.320 27285 2074 1114.8
< 850 N/mm² 2.20 2 180 0.040 1.760 0.330 26045 2084 1210.2
2.30 2 180 0.042 1.840 0.350 24910 2092 1347.5
2.40 2 180 0.044 1.920 0.360 23875 2101 1452.2
2.50 2 180 0.046 2.000 0.380 22920 2109 1602.5
3.00 2 180 0.054 2.400 0.450 19100 2063 2227.8
Steel 2.10 2 160 0.034 1.680 0.320 24250 1649 886.5
850 - 1100 N/mm² 2.20 2 160 0.036 1.760 0.330 23150 1667 968.1
2.30 2 160 0.038 1.840 0.350 22145 1683 1083.9
2.40 2 160 0.040 1.920 0.360 21220 1698 1173.4
2.50 2 160 0.042 2.000 0.380 20370 1711 1300.4
3.00 2 160 0.048 2.400 0.450 16975 1630 1760.0
Inox normal 2.10 2 70 0.030 1.680 0.320 10610 637 342.2
[Cr-Ni/1.4301] 2.20 2 70 0.032 1.760 0.330 10130 648 376.5
[Cr-Ni-Mo/1.4571] 2.30 2 70 0.034 1.840 0.350 9690 659 424.3
2.40 2 70 0.036 1.920 0.360 9285 669 462.1
2.50 2 70 0.036 2.000 0.380 8915 642 487.8
3.00 2 70 0.044 2.400 0.450 7425 653 705.7
Titanium alloys 2.10 2 60 0.026 1.680 0.320 9095 473 254.2
up to 300 HB 2.20 2 60 0.028 1.760 0.330 8680 486 282.3
[Ti5Al2.5Sn] 2.30 2 60 0.030 1.840 0.350 8305 498 320.9
2.40 2 60 0.030 1.920 0.360 7960 478 330.1
2.50 2 60 0.032 2.000 0.380 7640 489 371.6
3.00 2 60 0.038 2.400 0.450 6365 484 522.4
Steel 2.10 2 160 0.036 0.250 2.100 24250 1746 916.7
< 850 N/mm² 2.20 2 160 0.036 0.260 2.200 23150 1667 953.4
2.30 2 160 0.038 0.280 2.300 22145 1683 1083.9
2.40 2 160 0.040 0.290 2.400 21220 1698 1181.5
2.50 2 160 0.042 0.300 2.500 20370 1711 1283.3
3.00 2 160 0.050 0.360 3.000 16975 1698 1833.3
Steel 2.10 2 140 0.034 0.250 2.100 21220 1443 757.6
850 - 1100 N/mm² 2.20 2 140 0.034 0.260 2.200 20255 1377 787.8
2.30 2 140 0.036 0.280 2.300 19375 1395 898.4
2.40 2 140 0.038 0.290 2.400 18570 1411 982.3
2.50 2 140 0.040 0.300 2.500 17825 1426 1069.5
3.00 2 140 0.048 0.360 3.000 14855 1426 1540.2
Inox normal 2.10 2 60 0.032 0.250 2.100 9095 582 305.6
[Cr-Ni/1.4301] 2.20 2 60 0.032 0.260 2.200 8680 556 317.7
[Cr-Ni-Mo/1.4571] 2.30 2 60 0.034 0.280 2.300 8305 565 363.7
2.40 2 60 0.036 0.290 2.400 7960 573 398.9
2.50 2 60 0.036 0.300 2.500 7640 550 412.6
3.00 2 60 0.044 0.360 3.000 6365 560 604.9
Titanium alloys 2.10 2 50 0.028 0.250 2.100 7580 425 222.9
up to 300 HB 2.20 2 50 0.028 0.260 2.200 7235 405 231.8
[Ti5Al2.5Sn] 2.30 2 50 0.030 0.280 2.300 6920 415 267.4
2.40 2 50 0.032 0.290 2.400 6630 424 295.3
2.50 2 50 0.034 0.300 2.500 6365 433 324.6
3.00 2 50 0.040 0.360 3.000 5305 424 458.4
fraisa.com
290
