TOLERANCES                                                    Series 1580KH, 1280KH, 1880KH
                d    +.0000" –.0005" (+.0000 –.0127mm)
                   ≤ 1/8"  +.125" –.062" (+3.175 –1.588mm)
               l1
                   > 1/8"  +.125" –.125" (+3.175 –3.175mm)                                            .1181" - .1540"
                   ≤ 1/8"  +.125" –.062" (+3.175 –1.588mm)
               l2                                                                                (3.000mm - 3.912mm)
                   >1/8"  +.125" –.125" (+3.175 –3.175mm)
                                                                 3xD   5xD    7xD        332-333

              AlTiN-based Coating                                                                               DRILLS  HIGH PERFORMANCE
              AlTiN-basierte-Beschichtet
              Recubrimiento a base de AlTiN
              Revêtement à base de AlTiN

              Rivestimento in a base AlTiN
                    涂层
              AlTiN基涂层
                  基



                High performance - high penetration solid submicron grain carbide drill
                Coolant through capabilities for high pressure coolant systems
                Extended tool life and greater surface finish through faster SFM rates
                Up to 70% faster than standard carbide drills
                30° helix for better chip evacuation
                Honed cutting edge
                Recommended to run in high nickel, high temperature alloys, cobalt-based alloys,  3xD  5xD  7xD  d  †   l1  l2
                stainless steels and tool steels > 40Rc    (1580KH)  (1280KH)  (1880KH)
                                                                                                            Flute
                Live tooling recommended on lathe processes  EDP#  EDP#  EDP#  Decimal  Diameter  Metric  Overall  Length
                                                                                                    Length
                Shank tolerance:  h6
                                                           22010               .1181         3.000   46      16
                                                                  25366        .1181         3.000   50      19
                Hohe Leistung – Hohe Vorschubgeschwindigkeiten- Vollhartmetallbohrer aus Feinkornhartmetall
                Kühlkanäle für Hochdruck Kühlmittelsysteme              26366  .1181         3.000   65      28
                Bis zu 70% schneller als Standard Hartmetallbohrer  22015      .1200   #31   3.048  1-13/16"  5/8"
                30° Spirale für bessere Spanabfuhr                25371        .1200   #31   3.048   2"     3/4"
                Gehonte Schneidkante
                Empfohlen für Hoch Nickelhaltige und Hochwarmfeste Stähle, Kobaltbasislegierungen,  26371  .1200  #31  3.048  2-1/2"  1-1/8"
                Rostfreier- und Werkzeugstahl > 40HRc      22020               .1250  1/8"   3.175  1-15/16"  11/16"
                Empfehlung fuer den Einsatz auf der Drehmaschine  25376        .1250  1/8"   3.175   2"     3/4"
                Schaft-Toleranz:  h6
                                                                        26376  .1250  1/8"   3.175  2-1/2"  1-1/8"
                                                           22025               .1285   #30   3.264  1-15/16"  11/16"
                                                                  25381        .1285   #30   3.264  2-1/4"  3/4"
                Broca de submicrograno sólido carburo de alto rendimiento
                Orificios de paso refrigerante concebidos para sistemas de refrigeración de alta presión  26381  .1285  #30  3.264  2-1/2"  1-1/8"
                Hasta un 70% más rápidas que las brocas de carburo convencionales  22030  .1360  #29  3.454  2-1/16"  3/4"
                Hélice de 30° para una mejor evacuación de viruta  25386       .1360   #29   3.454  2-1/4"  7/8"
                Labio cortante afilado
                Recomendado para aleaciones con alto contenido de níquel, aleaciones de alta temperatura,  26386  .1360  #29  3.454  3"  1-1/4"
                aleaciones con base de cobalto, aceros inoxidables, y aceros de herramienta > 40Rc  22035  .1378  3.500  52  19
                Recomendación para la aplicación en torno
                Tolerancia del vástago:  h6                       25391        .1378         3.500   57      22
                                                                        26391  .1378         3.500   75      32
                                                           22040               .1405   #28   3.569  2-1/16"  3/4"
                Forets carbure submicrograin a haute performance – haut pouvoir de coupe  25396  .1405  #28  3.569  2-1/4"  7/8"
                Canaux de refroidissement pour forte pression de systèmes de liquide de refroidissement  26396  .1405  #28  3.569  3"  1-1/4"
                70% plus rapide que les forets carbure standarts
                Helice a 30° pour une meilleure evacuation de copeaux  22045   .1406  9/64"  3.571  2-1/16"  3/4"
                Preparation de l’arete de coupe                   25401        .1406  9/64"  3.571  2-1/4"  7/8"
                Recommander pour base nickel, alliages a hautes temperatures, alliages de cobalt,  26401  .1406  9/64"  3.571  3"  1-1/4"
                aciers inoxydables et aciers a outils > 40HRC
                Outil de filature nécessaires pour une utilisation sur un processus de tournage  22050  .1440  #27  3.658  2-1/16"  3/4"
                Tolerance queue:  h6                              25406        .1440   #27   3.658  2-1/4"  7/8"
                                                                        26406  .1440   #27   3.658   3"     1-3/8"
                                                           22055               .1470   #26   3.734  2-3/16"  13/16"
                Alte prestazioni – Alta penetrazioni Super sub-micrograno metallo duro  25411  .1470  #26  3.734  2-1/4"  7/8"
                Lubrificazione interna per sistemi ad alta pressione
                Fino al 70% più veloce rispetto alle punte in metallo duro standard  26411  .1470  #26  3.734  3"  1-3/8"
                Elica a 30° per una migliore evacuazione del truciolo  22060   .1495   #25   3.797  2-3/16"  13/16"
                Tagliente onato                                   25416        .1495   #25   3.797  2-1/4"  15/16"
                Raccomandata per lavorazioni su nickel, superleghe, leghe ad alta percentuale di cobalto,
                inox e acciai per utensili > 40Hrc                      26416  .1495   #25   3.797   3"     1-3/8"
                Utensili rotanti sono consigliate se usato su un tornio  22065  .1520  #24   3.861  2-3/16"  13/16"
                Tolleranza gambo:  h6
                                                                  25421        .1520   #24   3.861  2-1/4"  15/16"
                                                                        26421  .1520   #24   3.861   3"     1-1/2"
                                                           22070               .1540   #23   3.912  2-3/16"  13/16"
                高效率—高进给 高效整体硬质合金钻头                                25426        .1540   #23   3.912  2-1/4"  15/16"
                通过加快切削速度延长刀具使用寿命、提高表面光洁度
                跟普通的硬质合金钻头相比可提高速度高达70%                                  26426  .1540   #23   3.912   3"     1-1/2"
                30° 螺旋角更便于排屑
                切削刃口经过珩磨
                高镍耐高温合金、钴基合金、不锈钢和工具钢 > 40HRC
                不建议在车床,或工具必须纺纱
                柄部公差:  h6                                                           continued              ?
