Page 68 - GARR_TOOL(CATALOG_INT)

Series 1520, 1205 (continued)

.1040" - .1719"
(2.642mm - 4.366mm)
GENERAL PURPOSE DRILLS EDP# EDP# Diameter Overall Flute

d
†
5xD
3xD
l2
l1
(1520)
(1205)
Length
Length
77265
2.642
.1040
2.642
#37
1-1/4"
.1040
2-1/4"
.1065
#36
13/16"
77270 89265 Decimal #37 Metric 1-13/16" 13/16"
2.705
1-13/16"
89270 .1065 #36 2.705 2-1/4" 1-1/4"
77275 .1094 7/64" 2.779 1-13/16" 13/16"
89275 .1094 7/64" 2.779 2-1/4" 1-1/4"
77280 .1100 #35 2.794 1-7/8" 7/8"
89280 .1100 #35 2.794 2-1/4" 1-1/4"
77285 .1110 #34 2.819 1-7/8" 7/8"
89285 .1110 #34 2.819 2-1/4" 1-1/4"
77290 .1130 #33 2.870 1-7/8" 7/8"
89290 .1130 #33 2.870 2-1/4" 1-1/4"
77295 .1160 #32 2.946 1-7/8" 7/8"
89295 .1160 #32 2.946 2-1/4" 1-1/4"
77300 .1181 3.000 48 22
89300 .1181 3.000 57 32
77305 .1200 #31 3.048 1-7/8" 7/8"
89305 .1200 #31 3.048 2-1/4" 1-1/4"
77310 .1250 1/8" 3.175 1-7/8" 7/8"
89310 .1250 1/8" 3.175 2-1/4" 1-1/4"
77315 .1285 #30 3.264 1-15/16" 15/16"
89315 .1285 #30 3.264 2-1/4" 1-1/4"
77320 .1360 #29 3.454 1-15/16" 15/16"
89320 .1360 #29 3.454 2-1/2" 1-3/8"
77325 .1378 3.500 49 24
89325 .1378 3.500 63 35
77330 .1405 #28 3.569 1-15/16" 15/16"
89330 .1405 #28 3.569 2-1/2" 1-3/8"
77335 .1406 9/64" 3.571 1-15/16" 15/16"
89335 .1406 9/64" 3.571 2-1/2" 1-3/8"
77340 .1440 #27 3.658 2-1/16" 1"
89340 .1440 #27 3.658 2-1/2" 1-3/8"
77345 .1470 #26 3.734 2-1/16" 1"
89345 .1470 #26 3.734 2-1/2" 1-3/8"
77350 .1495 #25 3.797 2-1/16" 1"
89350 .1495 #25 3.797 2-1/2" 1-3/8"
77355 .1520 #24 3.861 2-1/16" 1"
89355 .1520 #24 3.861 2-1/2" 1-3/8"
77360 .1540 #23 3.912 2-1/16" 1"
89360 .1540 #23 3.912 2-1/2" 1-3/8"
77365 .1562 5/32" 3.967 2-1/16" 1"
89365 .1562 5/32" 3.967 2-1/2" 1-3/8"
77370 .1570 #22 3.988 2-1/8" 1-1/16"
89370 .1570 #22 3.988 2-1/2" 1-3/8"
77375 .1575 4.000 54 27
89375 .1575 4.000 63 35
77380 .1590 #21 4.039 2-1/8" 1-1/16"
89380 .1590 #21 4.039 2-1/2" 1-3/8"
77385 .1610 #20 4.089 2-1/8" 1-1/16"
89385 .1610 #20 4.089 2-1/2" 1-3/8"
77390 .1660 #19 4.216 2-1/8" 1-1/16"
89390 .1660 #19 4.216 2-3/4" 1-5/8"
77395 .1695 #18 4.305 2-1/8" 1-1/16"
89395 .1695 #18 4.305 2-3/4" 1-5/8"
77400 .1719 11/64" 4.366 2-1/8" 1-1/16"
89400 .1719 11/64" 4.366 2-3/4" 1-5/8"
