Series 1200 (continued)

.1590" - .3346"
(4.039mm - 8.500mm)
GENERAL PURPOSE DRILLS EDP# Diameter Overall Flute

d
†
l2
l1
4.039
56380
.1590
1-3/8"
2-1/2"
1-3/8"
4.089
.1610
#20
56385
2-1/2"
#19
1-5/8"
.1660
56390 Decimal #21 Metric Length Length
4.216
2-3/4"
56395 .1695 #18 4.305 2-3/4" 1-5/8"
56400 .1719 11/64" 4.366 2-3/4" 1-5/8"
56405 .1730 #17 4.394 2-3/4" 1-5/8"
56410 .1770 #16 4.496 2-3/4" 1-5/8"
56415 .1772 4.500 70 41
56420 .1800 #15 4.572 2-3/4" 1-5/8"
56425 .1820 #14 4.623 2-3/4" 1-5/8"
56430 .1850 #13 4.700 2-3/4" 1-5/8"
56435 .1875 3/16" 4.763 2-3/4" 1-5/8"
56440 .1890 #12 4.801 2-3/4" 1-5/8"
56445 .1910 #11 4.851 2-3/4" 1-5/8"
56450 .1935 #10 4.915 2-3/4" 1-5/8"
56455 .1960 #9 4.978 3" 1-3/4"
56460 .1969 5.000 76 44
56465 .1990 #8 5.055 3" 1-3/4"
56470 .2010 #7 5.105 3" 1-3/4"
56475 .2031 13/64" 5.159 3" 1-3/4"
56480 .2040 #6 5.182 3" 1-3/4"
56485 .2055 #5 5.220 3" 1-3/4"
56490 .2090 #4 5.309 3" 1-3/4"
56495 .2130 #3 5.410 3" 1-3/4"
56500 .2165 5.500 76 44
56505 .2188 7/32" 5.558 3" 1-3/4"
56510 .2210 #2 5.613 3" 1-3/4"
56515 .2280 #1 5.791 3" 1-3/4"
56520 .2340 A 5.944 3-1/4" 2"
56525 .2344 15/64" 5.954 3-1/4" 2"
56530 .2362 6.000 82 50
56535 .2380 B 6.045 3-1/4" 2"
56540 .2420 C 6.147 3-1/4" 2"
56545 .2460 D 6.248 3-1/4" 2"
56550 .2500 1/4" / E 6.350 3-1/4" 2"
56555 .2559 6.500 82 50
56560 .2570 F 6.528 3-1/4" 2"
56565 .2610 G 6.629 3-1/2" 2-1/8"
56570 .2656 17/64" 6.746 3-1/2" 2-1/8"
56575 .2660 H 6.756 3-1/2" 2-1/8"
56580 .2720 I 6.909 3-1/2" 2-1/8"
56585 .2756 7.000 88 54
56590 .2770 J 7.036 3-1/2" 2-1/8"
56595 .2810 K 7.137 3-1/2" 2-1/8"
56600 .2812 9/32" 7.142 3-1/2" 2-1/8"
56605 .2900 L 7.366 3-1/2" 2-1/8"
56610 .2950 M 7.493 3-3/4" 2-3/8"
56615 .2953 7.500 95 60
56620 .2969 19/64" 7.541 3-3/4" 2-3/8"
56625 .3020 N 7.671 3-3/4" 2-3/8"
56630 .3125 5/16" 7.938 3-3/4" 2-3/8"
56635 .3150 8.000 95 60
56640 .3160 O 8.026 3-3/4" 2-3/8"
56645 .3230 P 8.204 3-3/4" 2-3/8"
56650 .3281 21/64" 8.334 4" 2-1/2"
56655 .3320 Q 8.433 4" 2-1/2"
56660 .3346 8.500 101 63
