INDEXABLE DRILLS D3N A-1.5D DCN (1) DCX (2) PL DCONMS LPR 20.00 OAL 20.71 42.92 DCONMS h6 DF 90.92 SSC (3) K D3N 12-13.99

Exchangeable Head 3 Flute Drills
with Coolant Holes and One Flat
DCN-DCX k7
Shank, Drilling Depth 1.5xD
LU

PL
LU
LPR
DF
Designation
OAL
D3N 120-018-16A-1.5D
16.00
12.40
12
12.00
2.710
D3N 125-019-16A-1.5D
12.50
12.90
92.42
2.710
K D3N 12-13.99
12
20.00
16.00
44.42
21.46
D3N 130-020-16A-1.5D
13.00
94.58
2.910
46.58
22.41
20.00
16.00
13.40
13
K D3N 12-13.99
D3N 135-020-16A-1.5D
96.08
14.40
24.10
20.00
16.00
D3N 140-021-16A-1.5D
14.00
98.08
14
50.08
3.100
K D3N 14-15.99
3.100
D3N 145-022-16A-1.5D
14.50
14.90
14
99.58
K D3N 14-15.99
51.58
20.00
24.85
16.00
25.00
25.97
15
3.470
20.00
K D3N 14-15.99
53.66
15.90
15.00
D3N 150-023-20A-1.5D
16
57.25
27.44
25.00
107.25
20.00
16.00
K D3N 16-17.99
16.90
3.440
D3N 160-024-20A-1.5D 13.50 13.90 16.00 20.00 23.16 48.08 2.910 103.66 13 K D3N 12-13.99
D3N 170-026-20A-1.5D 17.00 17.90 20.00 25.00 29.02 60.72 3.520 110.72 17 K D3N 16-17.99
D3N 180-027-25A-1.5D 18.00 18.90 25.00 32.00 30.90 64.36 3.900 120.36 18 K D3N 18-19.99
D3N 190-029-25A-1.5D 19.00 19.90 25.00 32.00 32.60 67.92 4.100 123.92 19 K D3N 18-19.99
D3N 200-030-25A-1.5D 20.00 20.90 25.00 32.00 34.32 71.24 4.320 127.24 20 K D3N 20-21.99
D3N 210-032-25A-1.5D 21.00 21.90 25.00 32.00 36.05 74.80 4.550 130.80 21 K D3N 20-21.99
D3N 220-033-25A-1.5D 22.00 22.90 25.00 32.00 37.69 78.62 4.690 134.62 22 K D3N 22-23.99
D3N 230-035-32A-1.5D 23.00 23.90 32.00 40.00 39.41 82.00 4.910 142.00 23 K D3N 22-23.99
D3N 240-036-32A-1.5D 24.00 24.90 32.00 40.00 41.21 85.54 5.210 145.54 24 K D3N 24-25.99
D3N 250-038-32A-1.5D 25.00 25.90 32.00 40.00 42.81 89.22 5.310 149.11 25 K D3N 24-25.99
• Do not mount smaller drilling heads other than the specified range of the drill body • For user guide and cutting conditions, see pages 68-81
(1) Cutting diameter minimum
(2) Cutting diameter maximum
(3) Seat size code
For inserts, see pages: H3P (62) • F3P (65)

OAL

D3N R-1.5D PL LPR
Exchangeable Head 3 Flute Drills
with Coolant Holes and A Round DCN-DCX k7 DCONMS h6 DF
Shank, Drilling Depth 1.5xD
LU
Designation DCN (1) DCX (2) DCONMS DF LU LPR PL OAL SSC (3)
D3N 120-018-16R-1.5D 12.00 12.40 16.00 20.00 20.71 42.92 2.710 90.92 12 K D3N 12-13.99
D3N 125-019-16R-1.5D 12.50 12.90 16.00 20.00 21.46 44.42 2.710 92.42 12 K D3N 12-13.99
D3N 130-020-16R-1.5D 13.00 13.40 16.00 20.00 22.41 46.58 2.910 94.58 13 K D3N 12-13.99
D3N 135-020-16R-1.5D 13.50 13.90 16.00 20.00 23.16 48.08 2.910 96.08 13 K D3N 12-13.99
D3N 140-021-16R-1.5D 14.00 14.40 16.00 20.00 24.10 50.08 3.100 98.08 14 K D3N 14-15.99
D3N 145-022-16R-1.5D 14.50 14.90 16.00 20.00 24.85 51.58 3.100 99.58 14 K D3N 14-15.99
D3N 150-023-20R-1.5D 15.00 15.90 20.00 25.00 25.97 53.66 3.470 103.66 15 K D3N 14-15.99
D3N 160-024-20R-1.5D 16.00 16.90 20.00 25.00 27.44 57.25 3.440 107.25 16 K D3N 16-17.99
D3N 170-026-20R-1.5D 17.00 17.90 20.00 25.00 29.02 60.72 3.520 110.72 17 K D3N 16-17.99
D3N 180-027-25R-1.5D 18.00 18.90 25.00 32.00 30.90 64.36 3.900 120.36 18 K D3N 18-19.99
D3N 190-029-25R-1.5D 19.00 19.90 25.00 32.00 32.60 67.92 4.100 123.92 19 K D3N 18-19.99
D3N 200-030-25R-1.5D 20.00 20.90 25.00 32.00 34.32 71.24 4.320 127.24 20 K D3N 20-21.99
D3N 210-032-25R-1.5D 21.00 21.90 25.00 32.00 36.05 74.80 4.550 130.80 21 K D3N 20-21.99
D3N 220-033-25R-1.5D 22.00 22.90 25.00 32.00 37.69 78.62 4.690 134.62 22 K D3N 22-23.99
D3N 230-035-32R-1.5D 23.00 23.90 32.00 40.00 39.41 82.00 4.910 142.00 23 K D3N 22-23.99
D3N 240-036-32R-1.5D 24.00 24.90 32.00 40.00 41.21 85.54 5.210 145.54 24 K D3N 24-25.99
D3N 250-038-32R-1.5D 25.00 25.90 32.00 40.00 42.81 89.22 5.310 149.11 25 K D3N 24-25.99
• Do not mount smaller drilling heads other than the specified range of the drill body • For user guide and cutting conditions, see pages 68-81
(1) Cutting diameter minimum
(2) Cutting diameter maximum
(3) Seat size code
For inserts, see pages: H3P (62) • F3P (65)
