INDEXABLE DRILLS FCP (continued) Dimensions KCH LF SIG PDD CHW DC

Exchangeable Flat Bottom
Drilling Heads for DCN
Drills, for Machining ISO
P and ISO K Materials
PL

Designation
DC
PL
LF
FCP 260
0.40
9.70
8.00
26.0
140
60.0
•
0.40
26.50
60.0
9.70
1.990
8.00
140
26.0
FCP 265
•
2.050
27.0
FCP 270
60.0
140
0.40
8.10
27.00
•
0.40
27.50
10.40
27.0
140
60.0
2.050
FCP 275 26.00 PDD 10.40 1.990 CHW KCH SIG SSC (1) • IC908
8.10
FCP 280 28.00 8.80 10.50 2.150 0.40 60.0 140 28.0 •
FCP 285 28.50 8.80 10.50 2.150 0.40 60.0 140 28.0 •
FCP 290 29.00 9.00 10.80 2.200 0.40 60.0 140 29.0 •
FCP 295 29.50 9.00 10.80 2.200 0.40 60.0 140 29.0 •
FCP 300 30.00 9.10 11.40 2.150 0.40 60.0 140 30.0 •
FCP 305 30.50 9.10 11.40 2.150 0.40 60.0 140 30.0 •
FCP 310 31.00 9.10 11.70 2.180 0.40 60.0 140 31.0 •
FCP 315 31.50 9.10 11.70 2.180 0.40 60.0 140 31.0 •
FCP 320 32.00 9.80 12.30 2.210 0.40 60.0 140 32.0 •
FCP 325 32.50 9.80 12.30 2.210 0.40 60.0 140 32.0 •
• For nearly flat bottom hole applications • For cutting conditions see page 68-81
(1) Seat size code
For tools, see pages: DCN A-1.5D (4) • DCN R-1.5D (5) • DCN A-3D (6) • DCN R-3D (7) • DCN A-5D (8) • DCN R-5D (9) • DCN A-8D (10) • DCN R-8D (11)
• DCN R-10D (11) • DCN R-12D (12) • DCN C-3D (13) • DCN C-5D (13) • DCN C-8D (14) • DCN C-12D (14) • DCNS-3D (15) • DCNS-5D (16) • DCNM (17)
• DCNT (M8-M24) (136)
