FACE MILLS IQ845 FSY-R05 DCONMS APMX OAL
DHUB
50° Face Mills Carrying Square
Inserts with 8 Cutting Edges
50°
DC
DCX

kg
OAL
Designation
DC
IQ845 FSY D040-04-16-R05
45.70
16.00
A
4
2.60
38.00
IQ845 FSY D040-07-16-R05 40.00 DCX (1) CICT (2) APMX 40.00 DHUB DCONMS Arbor (3) 0.28 SR M8X25DIN912 SR M2.5X6-T7-60 T-7/51
16.00
T-7/51
40.00
A
38.00
2.60
SR M2.5X6-T7-60
SR M8X25DIN912
45.70
7
0.26
40.00
IQ845 FSY D050-05-22-R05 50.00 55.80 5 2.60 40.00 48.00 22.00 A 0.44 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D050-09-22-R05 50.00 55.80 9 2.60 40.00 48.00 22.00 A 0.41 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D063-07-22-R05 63.00 68.80 7 2.60 40.00 48.00 22.00 B 0.57 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D063-11-22-R05 63.00 68.80 11 2.60 40.00 48.00 22.00 B 0.55 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: IQ845 SYHU-05 (499)
DHUB
DCONMS
F45WG
45° Face Mills Carrying
Octagonal ONHU/MU 0806... OAL
Inserts with 16 Cutting Edges 44.3°
DC APMX
DCX
Designation DC DCX (2) CICT (3) APMX OAL DHUB DCONMS Arbor (4) kg
F45WG D080-10-27-FX-R08 (1) 80.00 92.00 10 5.50 50.00 60.00 27.00 B 1.11
F45WG D100-14-32-FX-R08 (1) 100.00 112.00 14 5.50 50.00 70.00 32.00 B 1.64
F45WG D125-18-40-FX-R08 (1) 125.00 137.00 18 5.50 63.00 82.00 40.00 B 3.00
F45WG D160-22-40-FX-R08 160.00 172.00 22 5.50 63.00 92.00 40.00 C 4.58
• Note: Recommended wedge clamping torque: 8.5-9.0 Nxm • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Cutting diameter maximum
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: ONHQ-TN (498) • ONHU 0806-N-PL (499) • ONHU 0806AN-W (499) • ONHU/ONMU 080608 AN-N-HP (499) • ONHU/ONMU-08-TN-MM (498)
• ONHU/ONMU-08-TN/HL (498)
Wiper Inserts
Wiper inserts are used on face mill cutters, providing improved surface finish Mounting of Wiper Insert on
and thus eliminating the use of other finishing cutters. W2 Face Mills W2
ONHU 0806AN-14R-W mounted on F45WG and F45NM milling ONHU 0806AN-14R-W
cutters. This insert provides 4 right-hand wiper edges. W1
W1

Mounting instructions have been included in each insert W1 W2 W2 W1
package in order to avoid incorrect clamping orientation.
Only correct mounting will provide high surface finish!

Spare Parts

Designation
F45WG SR 118-069 BLD IP20/S7 SW6-T LW 35-475/M

220 ISCAR
