Page 225 - ISCAR(MILLINGCATALOG 38_2021)

1
DHUB 2 3 4 5

SOF45 DCONMS
Multifunction Face Mills for BD Rd°
Octagonal, Square and OAL OAL_2 OAL_3 15˚ OAL_4 44˚ OAL_5
Round Insert Contours with 44˚ 45˚
Various Entry Angles DC APMX DC_2 APMX_2 DC_3 APMX_3 DC_4 APMX_4 DC_5 APMX_5 FACE MILLS
DCX DCX_2 DCX_3 DCX_4 DCX_5
D4
Designation MIID (6) MIID_2 (7) MIID_3 (8) MIID_4 (9) MIID_5 (10)
SOF45 8/16-D040-04-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-03-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-04-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-06-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D050-04-22-R13 ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-04-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-06-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-08-22R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D063-06-22-R13 ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D080-07-27R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D080-10-27R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D080-07-27-R13 ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D100-08-32R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D100-12-32R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D100-08-32-R13 ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D125-10-40R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D125-16-40R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D125-10-40-R13 ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D160-12-40R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D200-14-60R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D250-16-60R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D315-20-60R ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
• 1- with ONMU 0505... insert • 2- with S845 SNMU 1305... insert • 3- with RXMT 1607N insert • 4- with OXMT 0507R08-FF insert
• 5- with OXMT 050705-R-HP insert • Use only Torx Plus keys • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Valid only with RXMT 1607N insert
(4) For adaptation options, see page 548
(5) 0 - Without coolant supply, 1 - With coolant supply
(6) Master insert identification
(7) Master insert identification 2
(8) Master insert identification 3
(9) Master insert identification 4
(10) Master insert identification 5
For inserts, see pages: ONHU 0505-W (505) • ONHU/ONMU-05 (504) • OXMT 0507 (505) • RXMT 1607 (527) • S845 SNHU 1305-W (501)
• S845 SNMU/SNHU-13 (500)

Spare Parts

Designation
SOF45 8/16-D040-04-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X25 DIN912
SOF45 8/16-D050-03-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D050-04-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D050-06-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X20DIN912
SOF45 D050-04-22-R13 SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D063-04-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH SR M10X25 DIN912
SOF45 8/16-D063-06-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D063-08-22R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 D063-06-22-R13 SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D080-07-27R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D080-10-27R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 D080-07-27-R13 SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D100-08-32R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D100-12-32R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 D100-08-32-R13 SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D125-10-40R
(a) IMPORTANT: Use only Torx Plus keys. SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D125-16-40R SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 D125-10-40-R13 SR 11800745 BLD IP15/S7 (a) SW6-T-SH
SOF45 8/16-D160-12-40R SR 11800745 BLD IP15/M7 (a) SW6-T-SH
SOF45 8/16-D200-14-60R SR 11800745 BLD IP15/M7 (a) SW6-T-SH
SOF45 8/16-D250-16-60R SR 11800745 BLD IP15/M7 (a) SW6-T-SH
SOF45 8/16-D315-20-60R SR 11800745 BLD IP15/M7 (a) SW6-T-SH

223
