SLOTTING & SLITTING CUTTERS
OAL
LF
DRVS
ETS-LN08-M DC THSZMS
Grooving and Slitting Cutters with
FLEXFIT Threaded Adaptation CDX DCONMS
CWN-CWX
Designation DC CWN (1) CWX (2) CDX (3) NOF (4) ZEFP DCONMS THSZMS LF OAL DRVS (5) TQ_3 (6)
(7)
ETS D032-03-LN08-M08 32.00 3.00 (7) 3.00 9.30 4 2 13.00 M08 13.00 30.50 10.0 20
ETS D032-04-LN08-M08 32.00 4.00 (8) 4.50 (11) 9.30 4 2 13.00 M08 13.00 30.50 10.0 20
ETS D032-05-LN08-M10 32.00 5.00 (9) 5.50 (12) 7.00 4 2 18.00 M10 13.00 33.00 16.0 29
ETS D032-06-LN08-M10 32.00 6.00 (10) 6.50 (13) 7.00 4 2 18.00 M10 13.00 33.00 16.0 29
ETS D040-03-LN08-M08 40.00 3.00 3.00 13.00 6 3 13.00 M08 13.00 30.50 10.0 20
(7)
(7)
ETS D040-04-LN08-M08 40.00 4.00 4.50 13.00 6 3 13.00 M08 13.00 30.50 10.0 20
(11)
(8)
ETS D040-05-LN08-M10 40.00 5.00 5.50 11.00 6 3 18.00 M10 13.00 33.00 16.0 29
(9)
(12)
(13)
(10)
ETS D040-06-LN08-M10 40.00 6.00 6.50 11.00 6 3 18.00 M10 13.00 33.00 16.0 29
(7)
ETS D050-03-LN08-M10 50.00 3.00 3.00 15.50 8 4 18.00 M10 13.00 33.00 16.0 29
(7)
(11)
(8)
ETS D050-04-LN08-M10 50.00 4.00 4.50 15.50 8 4 18.00 M10 13.00 33.00 16.0 29
(12)
(9)
ETS D050-05-LN08-M12 50.00 5.00 5.50 14.50 8 4 21.00 M12 13.00 35.00 17.0 33
ETS D050-06-LN08-M12 50.00 6.00 6.50 14.50 8 4 21.00 M12 13.00 35.00 17.0 33
(10)
(13)
ETS D063-03-LN08-M10 63.00 3.00 3.00 22.00 10 5 18.00 M10 13.00 33.00 16.0 29
(7)
(7)
ETS D063-04-LN08-M10 63.00 4.00 4.50 22.00 10 5 18.00 M10 13.00 33.00 16.0 29
(8)
(11)
ETS D063-05-LN08-M12 63.00 5.00 5.50 21.00 10 5 21.00 M12 13.00 35.00 17.0 33
(12)
(9)
(13)
(10)
ETS D063-06-LN08-M12 63.00 6.00 6.50 21.00 10 5 21.00 M12 13.00 35.00 17.0 33
• For user guide, see pages 377-383 • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly
cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
(4) Number of flutes
(5) Clamping wrench size
(6) Tool tightening torque Nxm (lbfxin)
(7) Use LNET 0818.. insert with SR 114-018-L2.50 screw
(8) Use LNET 0826.. insert with SR 114-018-L3.40 screw
(9) Use LNET 0830.. insert with SR 114-018-L4.40 screw
(10) Use LNET 0835.. insert with SR 114-018-L5.30 screw
(11) Use LNET 0828.. insert with SR 114-018-L3.40 screw
(12) Use LNET 0832.. insert with SR 114-018-L4.40 screw
(13) Use LNET 0837.. insert with SR 114-018-L5.30
For inserts, see pages: LNET 08 (492)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Cutter Designation CWN-CWX Inserts
ETS D...-03-..-LN08 3 LNET 081804-TN-N
4 LNET 082604-TN-N
ETS D...-04-..-LN08
4.5 LNET 082804-TN-N
5 LNET 0830-TN-N
ETS D...-05-..-LN08
5.5 LNET 0832-TN-N
6 LNET 0835-TN-N
ETS D...-06-..-LN08
6.5 LNET 0837-TN-N
Spare Parts
Designation
ETS D032-03-LN08-M08 SR 114-018-L2.50 T-6/3-L T-6/5
ETS D032-04-LN08-M08 SR 114-018-L3.40 T-6/3-L T-6/5
ETS D032-05-LN08-M10 SR 114-018-L4.40 T-6/3-L T-6/5 MM KEY 16X9*
ETS D032-06-LN08-M10 SR 114-018-L5.30 T-6/3-L T-6/5 MM KEY 16X9*
ETS D040-03-LN08-M08 SR 114-018-L2.50 T-6/3-L T-6/5
ETS D040-04-LN08-M08 SR 114-018-L3.40 T-6/3-L T-6/5
ETS D040-05-LN08-M10 SR 114-018-L4.40 T-6/3-L T-6/5 MM KEY 16X9*
ETS D040-06-LN08-M10 SR 114-018-L5.30 T-6/3-L T-6/5 MM KEY 16X9*
ETS D050-03-LN08-M10 SR 114-018-L2.50 T-6/3-L T-6/5
ETS D050-04-LN08-M10 SR 114-018-L3.40 T-6/3-L T-6/5
ETS D050-05-LN08-M12 SR 114-018-L4.40 T-6/3-L T-6/5 WRENCH ER11*
ETS D050-06-LN08-M12 SR 114-018-L5.30 T-6/3-L T-6/5 WRENCH ER11*
ETS D063-03-LN08-M10 SR 114-018-L2.50 T-6/3-L T-6/5
ETS D063-04-LN08-M10 SR 114-018-L3.40 T-6/3-L T-6/5
ETS D063-05-LN08-M12 SR 114-018-L4.40 T-6/3-L T-6/5 WRENCH ER11*
ETS D063-06-LN08-M12 SR 114-018-L5.30 T-6/3-L T-6/5 WRENCH ER11*
* Optional, should be ordered separately
