SLOTTING & SLITTING CUTTERS
                                                                     DHUB
                                                                    DCONMS
          FDN-XN13
          Full Slot Flange Type Slotting
          Cutters Carrying XNMU 1306
          Square Inserts with 4 Right- and                                   CDX      LU  OAL
          4 Left-Hand Cutting Edges                                                CW
                                                                      DC


           Designation          DC      CW    CICT (1)  ZEFP  CDX (2)  DHUB  DCONMS  LU     OAL   Arbor (3)  kg
           FDN D100-14-27-XN13  100.00  14.00   10     10     26.00  55.00   27.00   26.5   40.00   B      0.61
           FDN D125-14-32-XN13  125.00  14.00   12     12     33.00  65.00   32.00   30.5   45.00   B      1.04
           FDN D125-16-32-XN13  125.00  16.00   12     6      33.00  65.00   32.00   30.5   45.00   B      1.13
           FDN D160-18-40-XN13  160.00  18.00   14     7      45.00  80.00   40.00   44.0   60.00   B      2.24
           FDN D200-20-40-XN13  200.00  20.00   16     8      53.00  92.00   40.00   -      63.00   C      3.81
          •  For user guide, see pages 377-383
          (1)  Number of inserts
          (2)  Cutting depth maximum
          (3)  For adaptation options, see page 548
          For inserts, see pages: XNMU 13 (514)

          Spare Parts
           Designation
           FDN-XN13      SR M4-L15-D4.5  BLD IP15/S7  SW6-T-SH










                                                                     DHUB
                                                                    DCONMS

          FDN-CALN13
          Full Slot Adjustable Slotting
          Cutters with Cartridges Carrying                                      CDX    OAL
          T490 LNHT 1306PNTR/L Inserts
          (17.5-23.0 mm width range)                                                  CW
                                                                      DC

           Designation             CWN (1)  CWX (2)  CDX (3)  DC  DHUB  DCONMS  CICT (4)  ZEFP  OAL  Arbor (5)  kg
           FDN D125-1723-32R-CALN13  17.50  23.00  30.00  126.00  65.00  32.00  8     4     39.25    B     1.43
           FDN D160-1723-40R-CALN13  17.50  23.00  39.00  161.00  80.00  40.00  10    5     49.25    B     2.61
           FDN D200-1723-40R-CALN13  17.50  23.00  53.00  201.00  92.00  40.00  14    7     49.25    C     3.82
           FDN D250-1723-60R-CALN13  17.50  23.00  59.00  251.00  132.00  60.00  16   8     49.25    C     6.55
          •  Half of the inserts are used on right-hand cartridges and half on left-hand cartridges   •  For cartridge details, see page 363
          •   The cutter will be set to the minimum width range unless a specific width is requested by the user
          (1)  Minimum cutting width
          (2)  Maximum cutting width
          (3)  Cutting depth maximum
          (4)  Number of inserts
          (5)  For adaptation options, see page 548
          For inserts, see pages: T490 LNMT/LNHT/LNAR 1306 (478)

          Spare Parts
           Designation
           FDN-CALN13                 CA90 1723-R/L-T490-13
