Page 608 - ISCAR(MILLINGCATALOG 38_2021)

A 0.003 A 58-60 HRc
DIN 69893 HSK A / E
HSK-C#
CAMFIX (ISO 26623-1) DCONMS DCONWS
Holders with HSK DIN 69893
Form A Tapered Shanks
LB
LPR

Designation DCONMS DCONWS LPR LB CDI (1) kg
C4 AD HSK A63WHX080 63.00 40.00 80.00 54.00 1 1.10
C5 AD HSK A63WHX90 63.00 50.00 90.00 64.00 1 1.44
C5 AD HSK A100WHX100 100.00 50.00 100.00 71.00 1 2.90
C6 AD HSK A100WHX110 100.00 63.00 110.00 81.00 1 3.61
C8 AD HSK A100WHX120 100.00 80.00 120.00 91.00 1 4.79
C6 AD HSK A100-110 100.00 63.00 110.00 81.00 1 4.00
• Note: To enable clamping the part to be attached, first remove the cooling tube
(1) 1 - Hole for data chip, 0 - Without hole for data chip

Spare Parts
Designation
C4 AD HSK A63WHX080 SR M14X58 C4 HW 8.0* MT RING M22X17XC4 COOLING TUBE HSK A63 C5 WRENCH COOL TUBE HSK63* WRENCH C4 DRW NUT*
C5 AD HSK A63WHX90 SR M16X70 C5 HW 10.0* MT RING M25X20XC5 COOLING TUBE HSK A63 C5 WRENCH COOL TUBE HSK63* WRENCH C5 DRW NUT*
C5 AD HSK A100WHX100 SR M16X70 C5 HW 10.0* MT RING M25X20XC5 COOLING TUBE HSK A100 WRENCH COOL TUBE HSK100* WRENCH C5 DRW NUT*
C6 AD HSK A100WHX110 SR M20X87 C6/8 HW 14.0* MT RING M30X24XC6/8 COOLING TUBE HSK A100C6/8 WRENCH COOL TUBE HSK100* WRENCH C6-8 DRW NUT*
C8 AD HSK A100WHX120 SR M20X87 C6/8 HW 14.0* MT RING M30X24XC6/8 COOLING TUBE HSK A100C6/8 WRENCH COOL TUBE HSK100* WRENCH C6-8 DRW NUT*
* Optional, should be ordered separately

Tt˚ A 0.01 A 58-60 HRc
HSK A-MT
DIN 6383/DIN 228-2 Form D Tang DCONMS
Morse Taper Adapters with DIN BD
69893/A HSK Tapered Shanks
LB
LPR

Designation DCONMS Tt° BD LPR LB CDI (1) kg
HSK A63 MT1X110 63.00 MT1 25.00 110.00 84.0 1 0.92 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 MT2X120 63.00 MT2 32.00 120.00 94.0 1 1.09 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 MT3X140 63.00 MT3 40.00 140.00 114.0 1 1.45 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 MT4X160 63.00 MT4 48.00 160.00 134.0 1 1.89 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A100 MT1X110 100.00 MT1 25.00 110.00 81.0 1 2.27 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 MT2X120 100.00 MT2 32.00 120.00 91.0 1 2.39 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 MT3X150 100.00 MT3 40.00 150.00 121.0 1 2.83 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 MT4X170 100.00 MT4 48.00 170.00 141.0 1 3.31 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 MT5X200 100.00 MT5 63.00 200.00 171.0 1 4.60 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
* Optional, should be ordered separately
(1) 1 - Hole for data chip, 0 - Without hole for data chip

606 ISCAR
