DIN 69893 HSK A / E
LPR A 0.003 A 58-60 HRc
HSK A-ODP (FLEXFIT) LBX LB
FLEXFIT Threaded Adaptation 10 HSK A63=20,000RPM
G2.5
with HSK DIN69893/A U<1.0 gmm
G6.3
Tapered Shanks DCONMS BD HSK A100=12,000RPM
BD_2 THSZWS
.
Designation DCONMS THSZWS BD BD_2 LPR LBX LB CDI (1) kg
HSK A32 ODP12X42 32.00 M12 21.00 20.60 42.00 22.0 - 1 0.17 COOLING TUBE HSK A32* WRENCH COOL TUBE HSK32*
HSK A50 ODP12X48 50.00 M12 21.00 20.60 48.00 22.0 - 1 0.46 COOLING TUBE HSK A50* WRENCH COOL TUBE HSK50*
HSK A63 ODP6X109 63.00 M06 9.80 23.00 109.00 83.0 75.00 1 0.74 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP6X59 63.00 M06 9.80 11.50 59.00 33.0 25.00 1 0.66 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP8X109 63.00 M08 13.10 23.00 109.00 83.0 75.00 1 0.77 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP8X59 63.00 M08 13.10 15.00 59.00 33.0 25.00 1 0.68 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP10X109 63.00 M10 18.00 28.00 109.00 83.0 75.00 1 0.87 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP10X59 63.00 M10 18.00 20.00 59.00 33.0 25.00 1 0.70 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP12X109 63.00 M12 21.00 31.00 109.00 83.0 75.00 1 0.93 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP12X59 63.00 M12 21.00 23.50 59.00 33.0 25.00 1 0.71 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP16X109 63.00 M16 29.00 34.00 109.00 83.0 75.00 1 1.05 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A63 ODP16X59 63.00 M16 29.00 34.60 59.00 33.0 25.00 1 0.79 COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63*
HSK A100 ODP12X137 100.00 M12 23.00 30.00 137.00 108.0 100.00 1 2.58 COOLING TUBE HSK A100 WRENCH COOL TUBE HSK100
HSK A100 ODP12X187 100.00 M12 23.00 40.00 187.00 158.0 150.00 1 2.86 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP12X237 100.00 M12 23.00 46.00 237.00 208.0 200.00 1 3.40 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP12X87 100.00 M12 23.00 30.00 87.00 58.0 50.00 1 2.23 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP16X137 100.00 M16 29.00 41.50 137.00 108.0 100.00 1 2.68 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP16X187 100.00 M16 29.00 55.00 187.00 158.0 150.00 1 3.58 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP16X237 100.00 M16 29.00 55.00 237.00 208.0 200.00 1 4.07 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
HSK A100 ODP16X87 100.00 M16 29.00 31.50 87.00 58.0 50.00 1 2.20 COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
(1) 1 - Hole for data chip, 0 - Without hole for data chip
* Optional, should be ordered separately
664 666-668
LPR 58-60 HRc
HSK A-B-MN (blanks) LBX LB
Blanks with HSK DIN69893/A
Tapered Shanks
DCONMS BD
BD_2 .
Designation DCONMS BD BD_2 LPR LBX LB CDI (1) kg
HSK A63 B16MN 100 63.00 63.00 52.80 100.00 74.0 55.50 1 2.31
HSK A63 B16MN 200 63.00 63.00 52.80 200.00 174.0 155.50 1 4.75
HSK A100 B16MN 100 100.00 102.00 85.00 100.00 71.0 54.80 1 6.22
HSK A100 B16MN 200 100.00 102.00 85.00 200.00 171.0 154.80 1 12.90
• Material: Case hardened alloy steel, nose core hardness 22-30 HRC, nose surface hardness 57-60 HRC • Tensile strength: min 760 Mpa
(1) 1 - Hole for data chip, 0 - Without hole for data chip
Spare Parts
Designation
HSK A-B-MN (blanks) COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100*
* Optional, should be ordered separately
