ACCESSORIES & SPARE PARTS
OAL 58-60 HRc
PS BT-JIS (Pull Stud) LB_2
BT Pull Stud with JIS LB
6339 Retention Knob
BD_3 CND CRKS
BHTA BD_2 BD
Designation SS CRKS BD_3 BD_2 BD CND LB OAL LB_2 BHTA Fig. CSP (2)
PS BT30 15 M12 JISB 30 M12 12.00 8.00 12.50 4.0 18.40 43.0 23.40 75.0 1. 1
PS BT40 15 M16 JIS 4OB (1) 40 M16 19.00 14.00 17.00 4.0 23.00 54.0 29.00 75.0 2. 1
PS BT40 15 M16 JISB 40 M16 19.00 14.00 17.00 5.5 23.00 54.0 29.00 75.0 1. 1
PS BT40 15 M16 JISOB 40 M16 19.00 14.00 17.00 5.5 23.00 54.0 29.00 75.0 2. 1
PS BT40 15 M16 JISBO 40 M16 19.00 14.00 17.00 5.5 23.00 54.0 29.00 75.0 3. 1
PS BT50 15 M24 JIS B 50 M24 28.00 21.00 25.00 8.0 25.00 74.0 34.00 75.0 1. 1
PS BT50 15 M24 JIS OB 50 M24 28.00 21.00 25.00 8.0 25.00 74.0 34.00 75.0 2. 1
• Fig 1: With coolant holes only • Fig 2: With coolant holes and external O-ring • Fig 3: With coolant holes, external and internal O-rings
(1) 4 mm through hole for OKUMA machines
(2) 0 - Without coolant supply, 1 - With coolant supply

58-60 HRc
PS BT-MAZAK (Pull Stud) 1 LB_2 OAL 2
BT Pull Stud with ANSI Retention LB
Knob for MAZAK Machines
BD_3 CND CRKS
BD
BHTA
BD_2
Designation SS CRKS BD_3 BD_2 BD CND LB OAL LB_2 BHTA Fig. CSP (1)
PS BT40 45 M16 MAZAKB 40 M16 18.80 12.40 17.00 7.0 14.03 44.1 19.10 45.0 1 1
PS BT40 45 M16 MAZAKBO 40 M16 18.80 12.40 17.00 7.0 14.03 44.1 19.10 45.0 2 1
PS BT40 90 M16 MAZAK B 40 M16 15.00 10.00 17.00 - 22.60 54.6 29.60 90.0 1 0
PS BT50 45 M24 MAZAKB 50 M24 29.00 20.80 25.00 8.0 17.58 65.2 25.20 45.0 1 1
• Fig 1: With coolant hole only • Fig 2: With coolant hole and internal O-ring
(1) 0 - Without coolant supply, 1 - With coolant supply

Fig.1 Fig.2 Fig.3 58-60 HRc

PS BT-MAS (Pull Stud) LB_2 OAL
BT Pull Stud with MAS CND LB
Retention Knob
BD_3 CRKS
BHTA
BD_2 BD
Designation SS CRKS BD_3 BD_2 BD CND LB OAL LB_2 BHTA Fig. CSP (1)
PS BT30 45 M12 MAS1 30 M12 11.00 7.00 12.50 - 18.00 43.0 23.00 45.0 1. 0
PS BT30 45 M12 MAS1B 30 M12 11.00 7.00 12.50 3.0 18.00 43.0 23.00 45.0 1. 1
PS BT30 60 M12 MAS2 30 M12 11.00 7.00 12.50 - 18.00 43.0 23.00 60.0 1. 0
PS BT40 45 M16 MAS1 40 M16 15.00 10.00 17.00 - 28.00 60.0 35.00 45.0 1. 0
PS BT40 45 M16 MAS1B 40 M16 15.00 10.00 17.00 4.0 28.00 60.0 35.00 45.0 1. 1
PS BT40 60 M16 MAS2 40 M16 15.00 10.00 17.00 - 28.00 60.0 35.00 60.0 1. 0
PS BT40 60 M16 MAS2 B 40 M16 15.00 10.00 17.00 5.5 28.00 60.0 35.00 60.0 1. 1
PS BT40 90 M16 MAS3 40 M16 15.00 10.00 17.00 - 28.00 60.0 35.00 90.0 1. 0
PS BT40 90 M16 MAS3 B 40 M16 15.00 10.00 17.00 5.5 28.00 60.0 35.00 90.0 1. 1
PS BT50 45 M24 MAS1 50 M24 23.00 17.00 25.00 - 35.00 85.0 45.00 45.0 1. 0
PS BT50 45 M24 MAS1 B 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 45.0 1. 1
PS BT50 45 M24 MAS1 OB 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 45.0 2. 1
PS BT50 45 M24 MAS1 OBO 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 45.0 3. 1
PS BT50 60 M24 MAS2 50 M24 23.00 17.00 25.00 - 35.00 85.0 45.00 60.0 1. 0
PS BT50 60 M24 MAS2 OB 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 60.0 2. 1
PS BT50 60 M24 MAS2B 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 60.0 1. 1
PS BT50 90 M24 MAS3 50 M24 23.00 17.00 25.00 - 35.00 85.0 45.00 90.0 1. 0
PS BT50 90 M24 MAS3 B 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 90.0 1. 1
PS BT50 90 M24 MAS3 OB 50 M24 23.00 17.00 25.00 6.0 35.00 85.0 45.00 90.0 2. 1
PS BT50 90 M24 MAS3 OBO* 50 M24 23.00 17.00 25.00 8.0 35.00 85.0 45.00 90.0 3. 1
• Fig 1: With or without coolant holes (coolant holes only in items with a B suffix) • Fig 2: With coolant holes and external O-ring
• Fig 3: With coolant holes, external and internal O-rings
(1) 0 - Without coolant supply, 1 - With coolant supply
