ISOTURN INSERTS SNMG-F3M Dimensions 90° Tough 1 Hard Recommended Machining Data 45 º
75 º 45 º
75 º
Double-Sided Square
IC=L
Inserts for Stainless Steel
45°
75º
Finishing Applications
RE
S

f
ap
(mm)
Designation
RE
S
IC
SNMG 090404-F3M
9.52
0.05-0.30
•
•
4.76
SNMG 090408-F3M
9.52
0.80
0.05-0.30
0.50-3.50
•
•
•
0.40
0.90-3.50
SNMG 120404-F3M
0.10-0.40
4.76
•
•
•
•
•
12.70
0.10-0.40
0.90-3.50
4.76
SNMG 120408-F3M 12.70 4.76 0.40 • IC830 • IC6025 • IC6015 • IC806 • IC807 • IC804 0.50-3.50 (mm/rev)
0.80
SNMG 120412-F3M 12.70 4.76 1.20 • • • • • 0.90-3.50 0.10-0.40
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A-PSKNR/L-09 (115) • C#-MULNR/L-MW (16) • DSBNR/L (40) • DSDNN (39) • DSKNR/L (39) • DSSNR/L (39)
• HSK A63WH-MULNR-J12MWX2 (17) • HSK A63WH-MULNR/L-MW (16) • HSK A63WH-MUMNN-MW (17) • MULNR/L-12MW (15) • PSBNR/L (43) • PSDNN (41)
• PSDNN-JHP (41) • PSKNR/L (41) • PSSNR/L (42) • PSSNR/L-JHP (42)

45 º
SNMG-M3M 90° 75 º 75 º 45 º
Double-Sided Square Inserts
with a Special Chipformer IC=L 45°
for Heavy Machining 75º
RE S
Dimensions Tough 1 Hard Recommended Machining Data
IC830 IC6025 IC6015 IC806 IC807 IC804 ap f
Designation IC S RE (mm) (mm/rev)
SNMG 090404-M3M 9.52 4.76 0.40 • • 0.50-4.50 0.15-0.50
SNMG 090408-M3M 9.52 4.76 0.80 • • • • 0.50-4.50 0.15-0.50
SNMG 120408-M3M 12.70 4.76 0.80 • • • • • 0.50-5.00 0.15-0.50
SNMG 120412-M3M 12.70 4.76 1.20 • • • • • 0.50-5.00 0.20-0.60
SNMG 120416-M3M 12.70 4.76 1.60 • • • 0.50-5.00 0.25-0.70
SNMG 150612-M3M 15.88 6.35 1.20 • • • • 0.50-8.00 0.10-0.60
SNMG 150616-M3M 15.88 6.35 1.60 • • • • 0.50-8.00 0.10-0.65
SNMG 190612-M3M 19.05 6.35 1.20 • • 0.10-9.50 0.10-0.60
SNMG 190616-M3M 19.05 6.35 1.60 • • 0.10-9.50 0.10-0.65
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A-PSKNR/L-09 (115) • C#-MULNR/L-MW (16) • DSBNR/L (40) • DSDNN (39) • DSKNR/L (39) • DSSNR/L (39)
• HSK A63WH-MULNR-J12MWX2 (17) • HSK A63WH-MULNR/L-MW (16) • HSK A63WH-MUMNN-MW (17) • MULNR/L-12MW (15) • PSBNR/L (43)
• PSDNN (41) • PSDNN-JHP (41) • PSKNR/L (41) • PSSNR/L (42) • PSSNR/L-JHP (42)

45 º
SNMG-R3M 90° 75 º 75 º 45 º
Double-Sided 90° Square
Inserts for Rough Machining on IC=L 45°
Stainless and Low Carbon Steel 75º
RE S
Dimensions Tough 1 Hard Recommended Machining Data
IC830 IC806 ap f
Designation IC S RE (mm) (mm/rev)
SNMG 190612 R3M 19.05 6.35 1.20 • 2.00-11.00 0.30-0.90
SNMG 190616-R3M 19.05 6.35 1.60 • • 2.00-11.00 0.30-0.90
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: DSBNR/L (40) • DSDNN (39) • DSSNR/L (39) • PSBNR/L (43) • PSDNN (41) • PSSNR/L (42)
