Page 135 - DC_SWISS(Catalogue_TM_ES-EN)

HSSE DIN 374
MF ISO DIN 13

N460 3 N460V 3 N460TN 3 N460 3

N

N460-3 63 72 73 74 81 91
R40

N460V-3 V 11 12 32
R40

N460TN-3 TiN 11 12 13 14 32
R40

< 2.5 x D < 2.5 x D < 2.5 x D < 2.5 x D

a C C C C
d 2
2.5 x P 2.5 x P 2.5 x P 2.5 x P
d 1
l 2
l
1 P
Ø d 1 P l 1 l 2 d 2 a 6H ID ID ID ID 6H
MF mm mm mm mm mm + mm
12 1 100 14 9 7 3 11 l 102353 l 102462 l 102447 l 102352 0.026
12 1.25 100 14 9 7 3 10.8 l 102354 l 102463 l 144202
12 1.5 100 14 9 7 3 10.5 l 102356 l 102464 l 102448 l 102355 0.032
13 1 100 14 11 9 3 12 l 102364
14 1 100 14 11 9 3 13 l 102365 l 102466
14 1.5 100 14 11 9 3 12.5 l 102367 l 102467 l 102450 l 102366 0.032
15 1 100 14 12 9 3 14 l 102370
15 1.5 100 18 12 9 3 13.5 l 102371
16 1 100 14 12 9 4 15 l 102372 l 102469
16 1.5 100 14 12 9 4 14.5 l 102374 l 102470 l 102452 l 102373 0.032
18 1 110 18 14 11 4 17 l 102380 l 143926
18 1.5 110 18 14 11 4 16.5 l 102382 l 102472 l 145346 l 102381 0.032
20 1 125 20 16 12 4 19 l 102384 l 146377
20 1.5 125 20 16 12 4 18.5 l 102386 l 102474 l 148780
20 2 140 24 16 12 4 18 l 102387 l 143566
22 1 125 20 18 14.5 4 21 l 102392 l 147702
22 1.5 125 20 18 14.5 4 20.5 l 102393 l 102476
24 1.5 140 22 18 14.5 4 22.5 l 102396 l 102478
24 2 140 22 18 14.5 4 22 l 102397 l 102479
25 1.5 140 22 18 14.5 4 23.5 l 102399 l 143810
26 1.5 140 22 18 14.5 4 24.5 l 102400 l 143952
27 1.5 140 22 20 16 4 25.5 l 102401 l 143965
27 2 140 22 20 16 4 25 l 102402 l 144201
28 1.5 140 22 20 16 4 26.5 l 102403 l 144997
