DIN 371
PM
MF ISO DIN 13 DIN 374
H320 4 H420 4 H320TC 4 H420TC-4
H
H320-4 15 16 62 82
H420-4 15 16 62 82
NEW
NEW
H320TC-4 TiCN 15 16 24 31 82 83 NEW NEW
92 93
H420TC-4 TiCN 15 16 24 31 82 83
92 93
B B B B
a
d 2
4 x P 4 x P 4 x P 4 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a ID ID ID ID
MF mm mm mm mm mm mm
6 0.75 80 17 30 6 4.9 3 5.25 l 101214 l 196035
8 0.75 90 20 35 8 6.2 3 7.25 l 101216
8 1 90 20 35 8 6.2 3 7 l 101217 l 196036
10 1 100 22 39 10 8 3 9 l 101204 l 172963
10 1.25 100 22 39 10 8 3 8.8 l 175213 l 173079
12 1.25 100 24 9 7 4 10.8 l 101273
12 1.5 100 24 9 7 4 10.5 l 101274 l 196037
14 1.5 100 24 11 9 4 12.5 l 101276 l 164053
16 1.5 100 26 12 9 4 14.5 l 101278 l 196038
18 1.5 110 26 14 11 4 16.5 l 101280 l 196039
20 1.5 125 28 16 12 4 18.5 l 101282 l 148362
24 2 140 34 18 14.5 4 22 l 101285
