P. 142
PM DIN 371
MF ISO DIN 13 ~
SA390 3
SA390-3 16 53
R10
< 1.5 x D
< 1.5 x D
C
2.5 x P
P
Ø d 1 P l 1 l 2 d 2 a ID
MF mm mm mm mm mm
10 1 100 30 10 8 3 9 149751
12 1 110 35 12 9 4 11 149769
12 1.5 110 35 12 9 4 10.5 149773
14 1.5 110 40 16 12 4 12.5 149790
139
