P. 272

SK (1/4" Steel Shank)






       ROTARY FILES  Carbide Rotary Files - Taper Shape (90° Included Angle)




             Rotierende Hartmetallwerkzeuge - Kegelzapfenform (90° inclusive Winkel)
             Limas Rotativas de Carburo - Forma Cónica (Ángulo de cara de 90°)

             Fraises Limes Rotatives Carbure - Forme Conique (Forme conique a 90°)
             Lime Rotative in Metallo Duro - Geometria Conica (Angolo a 90°)
                             -
             硬质合金回转锉刀 - 退拔型 (90° 夹角)

                             退拔型
             硬质合金回转锉刀

                 Submicron Grain Carbide
                 1/4" (6,35mm) steel shank
                 D - Double Cut
                 ** - Solid Carbide/Double End
                                                                                 d1  †          d2     l4
                                                            EDP#  TOOL #        Diameter       Shank   Shank
                                                                         Decimal        Metric  Diameter  Length
                                                           68010  ** SK-1  .2500  1/4"  6.350   1/4"  1-11/16"
                                                           68012  ** SK-1D  .2500  1/4"  6.350  1/4"  1-11/16"
                 Feinkornhartmetall                        68020   SK-3   .3750  3/8"   9.525   1/4"  1-3/4"
                 1/4" (6,35mm) Stahlschaft
                 D - Doppelte Bearbeitung                  68022   SK-3D  .3750  3/8"   9.525   1/4"  1-3/4"
                 ** - Vollhartmetall / Doppel ende         68030   SK-5   .5000  1/2"   12.700  1/4"  1-3/4"
                                                           68032   SK-5D  .5000  1/2"   12.700  1/4"  1-3/4"
                                                           68040   SK-6   .6250  5/8"   15.875  1/4"  1-3/4"
                                                           68042   SK-6D  .6250  5/8"   15.875  1/4"  1-3/4"
                                                           68050   SK-7   .7500  3/4"   19.050  1/4"  1-3/4"
                                                           68052   SK-7D  .7500  3/4"   19.050  1/4"  1-3/4"
                 Submicrograno carburo
                 Espigas de acero de 1/4" (6,35mm)         68070   SK-9   1.000   1"    25.400  1/4"  1-3/4"
                 D - Corte doble                           68072   SK-9D  1.000   1"    25.400  1/4"  1-3/4"
                 ** - Carburo sólido / Doble punta





                 Carbure submicrograin
                 Queue acier 1/4" (6,35mm)
                 D - Double Coupe
                 ** - Carbure Plein / Double Extremite






                 Sub-micrograno metallo duro
                 Stelo in acciaio da 1/4" (6,35mm)
                 D - Doppio tagliente
                 ** - Metallo duro / Doppia fresa







                 超细晶粒硬质合金
                 1/4" (6,35mm) 钢质刀柄
                 D - 双切削
                 ** - 整体硬质合金 / 双头





        272     www.garrtool.com                                 ® ® ®   †  Metric equivalents are for reference only
