DIN69871-A/B DIN69871-EM SS DCONWS BD CRKS BD_2 LPR LPR LBX BD LB BD_2 CRKS LB CDI (1) DCONWS BD A 0.005 A AT3 Taper 58-60 HRc
For DCONWS ≥ 25
LBX
(DIN 6359-HB)
SS
DIN 69871 Form AD/B
Taper Shanks Holders with
DCONWS
DIN 6359-HB for DIN 1835
Form B Weldon Shanks
kg
Designation
DIN69871 30 EM 6X 50
SR M6X10 DIN1835B
6.00
DIN69871 30 EM 8X 50
M12
30.9
30
8.00
50.00
SR M8X10 DIN1835-B
28.00
0.49
DIN69871 30 EM10X 50
30.9
0.55
M12
35.00
50.00
30
48.00
M12
30
16.00
SR M14X16 DIN1835-B
DIN69871 30 EM16X 63 30 10.00 25.00 - - - - 50.00 30.9 - - - - M12 0 0 0 0 0.45 SR M10X12 DIN1835-B
63.00
0.81
43.9
DIN69871 30 EM18X 72 30 18.00 50.00 - 72.00 52.9 - M12 0 0.96 SR M14X16 DIN1835-B
DIN69871 30 EM20X72 30 20.00 52.00 - 72.00 52.9 - M12 0 0.96 SR M16X16 DIN1835-B
DIN69871 40 EM 6X 50 40 6.00 25.00 - 50.00 30.9 - M16 0 0.89 SR M6X10 DIN1835B
DIN69871 40 EM 8X 50 40 8.00 28.00 - 50.00 30.9 - M16 0 0.91 SR M8X10 DIN1835-B
DIN69871 40 EM10X 50 40 10.00 35.00 - 50.00 30.9 - M16 0 0.96 SR M10X12 DIN1835-B
DIN69871 40 EM12X 50 40 12.00 42.00 - 50.00 30.9 - M16 0 1.04 SR M12X16 DIN1835-B
DIN69871 40 EM14X 63 40 14.00 44.00 - 63.00 43.9 - M16 0 1.20 SR M12X16 DIN1835-B
DIN69871 40 EM16X 63 40 16.00 48.00 - 63.00 43.9 - M16 0 1.20 SR M14X16 DIN1835-B
DIN69871 40 EM18X 63 40 18.00 50.00 - 63.00 43.9 - M16 0 1.29 SR M14X16 DIN1835-B
DIN69871 40 EM20X 63 40 20.00 52.00 - 63.00 43.9 - M16 0 1.26 SR M16X16 DIN1835-B
DIN69871 40 EM25X100 40 25.00 65.00 49.00 100.00 80.9 65.00 M16 0 2.23 SR M18X2X20 DIN1835-B
DIN69871 40 EM32X100 40 32.00 71.00 49.00 100.00 80.9 65.00 M16 0 2.42 SR M20X2X20 DIN1835-B
DIN69871 50 EM 6X 63 50 6.00 25.00 - 63.00 43.9 - M24 0 2.70 SR M6X10 DIN1835B
DIN69871 50 EM 8X 63 50 8.00 28.00 - 63.00 43.9 - M24 0 2.73 SR M8X10 DIN1835-B
DIN69871 50 EM10X 63 50 10.00 35.00 - 63.00 43.9 - M24 0 2.83 SR M10X12 DIN1835-B
DIN69871 50 EM12X 63 50 12.00 42.00 - 63.00 43.9 - M24 0 2.93 SR M12X16 DIN1835-B
DIN69871 50 EM14X 63 50 14.00 44.00 - 63.00 43.9 - M24 0 2.91 SR M12X16 DIN1835-B
DIN69871 50 EM16X 63 50 16.00 48.00 - 63.00 43.9 - M24 0 3.02 SR M14X16 DIN1835-B
DIN69871 50 EM18X 63 50 18.00 50.00 - 63.00 43.9 - M24 0 3.08 SR M14X16 DIN1835-B
DIN69871 50 EM20X 63 50 20.00 52.00 - 63.00 43.9 - M24 0 3.07 SR M16X16 DIN1835-B
DIN69871 50 EM25X 80 50 25.00 65.00 - 80.00 60.9 - M24 0 3.70 SR M18X2X20 DIN1835-B
DIN69871 50 EM32X100 50 32.00 72.00 - 100.00 80.9 - M24 0 4.44 SR M20X2X20 DIN1835-B
DIN69871 50 EM40X100 50 40.00 90.00 79.90 100.00 80.9 43.00 M24 0 5.05 SR M20X2X20 DIN1835-B
DIN69871 50 EM50X125 50 50.00 98.00 79.90 125.00 105.9 90.00 M24 0 6.80 SR M24X2X25 DIN1835-B
(1) 1 - Hole for data chip, 0 - Without hole for data chip
