Page 580 - ISCAR(MILLINGCATALOG 38_2021)

SS LF LB LSCWS A 0.005 A AT3 Taper 58-60 HRc
DIN69871-A/B DIN 6358 COMBI Shell Mill SS DCONWS LF LSCWS LB LSCWS_2 BD DCONWS BD CDI (1) kg
DIN69871-SEMC
Holders with DIN 69871
Form AD Taper Shanks
CRKS
LSCWS_2

Designation
CRKS
DIN69871 30 SEMC 16X 50
50.00
DIN69871 30 SEMC 22X 50
30
31.00
40.00
30.9
0.61
M12
19.00
50.00
22.00
DIN69871 40 SEMC 16X 55
27.00
16.00
55.00
40
35.9
17.00
M16
1.01
32.00
1.30
17.00
DIN69871 40 SEMC 16X100 30 16.00 100.00 17.00 30.9 27.00 32.00 M12 0 0 0 0 0.53
32.00
16.00
M16
80.9
40
27.00
DIN69871 40 SEMC 22X 55 40 22.00 55.00 19.00 35.9 31.00 40.00 M16 0 1.05
DIN69871 40 SEMC 22X100 40 22.00 100.00 19.00 80.9 31.00 40.00 M16 0 1.47
DIN69871 40 SEMC 27X 55 40 27.00 55.00 21.00 35.9 33.00 48.00 M16 0 1.25
DIN69871 40 SEMC 27X100 40 27.00 100.00 21.00 80.9 33.00 48.00 M16 0 1.89
DIN69871 40 SEMC 32X 60 40 32.00 60.00 24.00 40.9 38.00 58.00 M16 0 1.41
DIN69871 40 SEMC 32X100 40 32.00 100.00 24.00 80.9 38.00 58.00 M16 0 2.24
DIN69871 40 SEMC 40X 60 40 40.00 60.00 27.00 40.9 41.00 70.00 M16 0 1.63
DIN69871 50 SEMC 16X 55 50 16.00 55.00 17.00 35.9 27.00 32.00 M24 0 2.80
DIN69871 50 SEMC 16X100 50 16.00 100.00 17.00 80.9 27.00 32.00 M24 0 3.54
DIN69871 50 SEMC 22X 55 50 22.00 55.00 19.00 35.9 31.00 40.00 M24 0 2.82
DIN69871 50 SEMC 22X100 50 22.00 100.00 19.00 80.9 31.00 40.00 M24 0 3.60
DIN69871 50 SEMC 27X 55 50 27.00 55.00 21.00 35.9 33.00 48.00 M24 0 3.06
DIN69871 50 SEMC 27X100 50 27.00 100.00 21.00 80.9 33.00 48.00 M24 0 3.82
DIN69871 50 SEMC 32X 55 50 32.00 55.00 24.00 35.9 38.00 58.00 M24 0 3.23
DIN69871 50 SEMC 32X100 50 32.00 100.00 24.00 80.9 38.00 58.00 M24 0 4.32
DIN69871 50 SEMC 40X 55 50 40.00 55.00 27.00 35.9 41.00 70.00 M24 0 3.43
DIN69871 50 SEMC 40X100 50 40.00 100.00 27.00 80.9 41.00 70.00 M24 0 5.24
DIN69871 50 SEMC 50X 70 50 50.00 70.00 30.00 50.9 46.00 90.00 M24 0 4.58
• For internal coolant through the holder, the related COOLANT SET should be ordered via Accessories (applicable to certain tools only)
(1) 1 - Hole for data chip, 0 - Without hole for data chip
712-713

Spare Parts
Designation
DIN69871 30 SEMC 16X 50 16 D.RING SEMC M8 CLAMP SCREW SEM16 WRENCH M8 SEMC16* KEY SEMC 16 4X4X20
DIN69871 30 SEMC 22X 50 22 D.RING SEMC M10 CLAMP SCREW SEM22 WRENCH M10 SEMC 22* KEY SEMC 22 6X6X25
DIN69871 40 SEMC 16X 55 16 D.RING SEMC M8 CLAMP SCREW SEM16 WRENCH M8 SEMC16* KEY SEMC 16 4X4X20
DIN69871 40 SEMC 16X100 16 D.RING SEMC M8 CLAMP SCREW SEM16 WRENCH M8 SEMC16* KEY SEMC 16 4X4X20
DIN69871 40 SEMC 22X 55 22 D.RING SEMC M10 CLAMP SCREW SEM22 WRENCH M10 SEMC 22* KEY SEMC 22 6X6X25
DIN69871 40 SEMC 22X100 22 D.RING SEMC M10 CLAMP SCREW SEM22 WRENCH M10 SEMC 22* KEY SEMC 22 6X6X25
DIN69871 40 SEMC 27X 55 27 D.RING SEMC M12 CLAMP SCREW SEM27 WRENCH M12 SEMC 27* KEY SEMC 27 7X7X25
DIN69871 40 SEMC 27X100 27 D.RING SEMC M12 CLAMP SCREW SEM27 WRENCH M12 SEMC 27* KEY SEMC 27 7X7X25
DIN69871 40 SEMC 32X 60 32 D.RING SEMC M16 CLAMP SCREW SEM32 WRENCH M16 SEMC 32* KEY SEMC 32 8X7X28
DIN69871 40 SEMC 32X100 32 D.RING SEMC M16 CLAMP SCREW SEM32 WRENCH M16 SEMC 32* KEY SEMC 32 8X7X28
DIN69871 40 SEMC 40X 60 40 D.RING SEMC M20 CLAMP SCREW SEM40 WRENCH M20 SEMC 40* KEY SEMC 40 10X8X32
DIN69871 50 SEMC 16X 55 16 D.RING SEMC M8 CLAMP SCREW SEM16 WRENCH M8 SEMC16* KEY SEMC 16 4X4X20
DIN69871 50 SEMC 16X100 16 D.RING SEMC M8 CLAMP SCREW SEM16 WRENCH M8 SEMC16* KEY SEMC 16 4X4X20
DIN69871 50 SEMC 22X 55 22 D.RING SEMC M10 CLAMP SCREW SEM22 WRENCH M10 SEMC 22* KEY SEMC 22 6X6X25
DIN69871 50 SEMC 22X100 22 D.RING SEMC M10 CLAMP SCREW SEM22 WRENCH M10 SEMC 22* KEY SEMC 22 6X6X25
DIN69871 50 SEMC 27X 55 27 D.RING SEMC M12 CLAMP SCREW SEM27 WRENCH M12 SEMC 27* KEY SEMC 27 7X7X25
DIN69871 50 SEMC 27X100 27 D.RING SEMC M12 CLAMP SCREW SEM27 WRENCH M12 SEMC 27* KEY SEMC 27 7X7X25
DIN69871 50 SEMC 32X 55 32 D.RING SEMC M16 CLAMP SCREW SEM32 WRENCH M16 SEMC 32* KEY SEMC 32 8X7X28
DIN69871 50 SEMC 32X100 32 D.RING SEMC M16 CLAMP SCREW SEM32 WRENCH M16 SEMC 32* KEY SEMC 32 8X7X28
DIN69871 50 SEMC 40X 55 40 D.RING SEMC M20 CLAMP SCREW SEM40 WRENCH M20 SEMC 40* KEY SEMC 40 10X8X32
DIN69871 50 SEMC 40X100 40 D.RING SEMC M20 CLAMP SCREW SEM40 WRENCH M20 SEMC 40* KEY SEMC 40 10X8X32
DIN69871 50 SEMC 50X 70 50 D.RING SEMC M24 CLAMP SCREW SEM50 WRENCH M24 SEMC 50* KEY SEMC 50 12X8X36
* Optional, should be ordered separately
