ISOTURN INSERTS CPMT-PF Dimensions RE IC L 80° 11° Tough 1 Hard ap Recommended
95 º
95 º
95 º
80° Rhombic Inserts with a
D1
Positive Flank for Semi-Finishing
and Finishing on Soft
Materials and Exotic Alloys
S

Machining Data

f
RE
IC
(mm)
Designation
S
L
D1
CPMT 060204-PF
0.04-0.30
•
•
•
6.30
0.50-2.50
6.35
2.80
0.08-0.30
2.38
0.80
CPMT 060208-PF
•
•
•
9.50
4.40
0.50-3.00
0.40
9.52
3.97
0.05-0.35
CPMT 09T304-PF
•
•
•
•
•
0.80
0.10-0.35
3.97
0.50-3.50
4.40
9.50
9.52
CPMT 09T308-PF 6.30 6.35 2.38 0.40 2.80 • IC830 • IC6025 • IC6015 • IC807 • IC907 0.50-2.50 (mm/rev)
• For user guide and cutting speed recommendations, see pages 122-134, 236-248

60° 27°
MAX
DCMT-F3P-SL 55° 62.5 º MAX
93 º
55° Rhombic Inserts with a
Positive Flank with a Locating IC D1 93º-95º
Bottom Ridge for Semi-Finishing 50º
MAX
and Finishing on Steel RE 7° S
L
Bottom view
Recommended
Dimensions Tough 1 Hard Machining Data
IC8250 IC8150 ap f
Designation L IC S RE D1 (mm) (mm/rev)
DCMT 13T504-F3P-SL 13.40 11.00 5.11 0.40 4.50 • • 0.50-3.00 0.05-0.25
DCMT 13T508-F3P-SL 13.40 11.00 5.11 0.80 4.50 • • 0.90-3.50 0.10-0.25
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A-SDUCR/L-13-SL (112) • AVC-SDJCN-Y (76) • C#-SDJCN-13-Y (76) • C#-SDJCR/L-13-SL-JHP (57) • C#-SDNCN-13-SL-JHP (63)
• HSK A63WH-SDJCN-13-Y (75) • SDACR/L-13S-SL-JHP (61) • SDJCR/L-13-SL (57) • SDNCN-13-SL (63)

107.5°
DCMT-F3P 55° 93º-95º 50º
55° Rhombic Inserts with a MAX
Positive Flank for Semi-Finishing IC D1
and Finish Turning on Steel
7°
RE
L S
Dimensions Tough 1 Hard Recommended
Machining Data
IC830 IC8250 IC8150 IC807 ap f
Designation L IC S RE D1 (mm) (mm/rev)
DCMT 070202-F3P 7.70 6.35 2.38 0.20 2.80 • • • • 0.06-1.50 0.03-0.12
DCMT 070204-F3P 7.70 6.35 2.38 0.40 2.80 • • • • 0.08-1.50 0.05-0.18
DCMT 11T302-F3P 11.60 9.52 3.97 0.20 4.40 • • • • 0.08-2.00 0.04-0.16
DCMT 11T304-F3P 11.60 9.52 3.97 0.40 4.40 • • • • 0.11-2.00 0.06-0.25
DCMT 11T308-F3P 11.60 9.52 3.97 0.80 4.40 • • • • 0.15-2.00 0.08-0.32
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: A/E/S-SDUCR/L (112) • AVC-SDUCR/L (95) • AVC-SDUCR/L-VH (98) • C#-SDJCR-JHP (59) • C#-SDJCR/L (59)
• C#-SDNCN (64) • E-SDUCR/L-HEAD (113) • NQCH-SDACR/L-S-JHP (60) • NQCH-Y-SDJCR-S-JHP (58) • PDACR/L-JHP (62) • PDACR/L-JHP-MC (62)
• PDACR/L-S (57) • SDACR/L (60) • SDHCR/L (59) • SDJCR-PAD (59) • SDJCR/L (58) • SDNCN (64) • Y-SDJCR (58) • Y-SDJCR-JHP (58)

190 ISCAR
