ISOTURN INSERTS SCMT-SM Dimensions 90° Tough 1 Hard ap Machining Data f 45°
45 º
45 º
75 º
Square Inserts with a 7°
D1
IC=L
Positive Flank for Semi-Finishing
and Finish Turning on Soft
7°
Materials and Exotic Alloys
RE
S
Recommended

RE
D1
Designation
L
S
(mm)
SCMT 09T304-SM
9.52
0.07-0.25
•
•
•
•
9.52
4.40
0.10-0.30
0.80
3.97
0.50-3.00
SCMT 09T308-SM
•
0.50-3.50
0.10-0.25
0.40
4.76
SCMT 120404-SM
5.50
•
•
•
•
1.00-4.00
4.76
0.10-0.30
SCMT 120408-SM 12.70 3.97 0.40 4.40 • IC830 • IC6025 • IC8250 • IC8150 • IC5005 • IC807 • IC907 0.50-3.00 (mm/rev)
5.50
12.70
0.80
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: SSBCR/L (70) • SSSCR/L (70)
90° 45 º

SCMT-14 45 º 75 º 45°
Square Inserts with a 7°
Positive Flank for Semi-Finishing IC=L D1
and Finish Turning on Soft
Materials and Exotic Alloys RE 7°
S
Dimensions Tough 1 Hard Recommended Machining Data
IC8250 IC807 IC907 ap f
Designation L S RE D1 (mm) (mm/rev)
SCMT 09T304-14 9.52 3.97 0.40 4.40 • • 1.00-3.50 0.12-0.30
SCMT 120404-14 12.70 4.76 0.40 5.50 • 1.00-4.00 0.12-0.30
• For user guide and cutting speed recommendations, see pages 122-134, 236-248
For tools, see pages: SSBCR/L (70) • SSSCR/L (70)
90°

SCMT-19 75 º
Square Inserts with a 7° Positive 45 º
Flank for Semi-Roughing at IC=L D1 45 º 45°
Medium to High Feeds
7°
RE
S
Dimensions Tough 1 Hard Recommended Machining Data
IC830 IC5005 IC807 IC907 ap fz
Designation L S RE D1 IC20 (mm) (mm/rev)
SCMT 120408-19 12.70 4.76 0.80 5.50 • • • • • 3.00-8.00 0.08-0.15
SCMT 120412-19 12.70 4.76 1.20 5.50 • 3.00-8.00 0.08-0.15
• For cutting speed recommendations, see pages
For tools, see pages: SSBCR/L (70) • SSSCR/L (70)
RE

XOMT-DT 88º
Inserts for DR Drills
and Boring Bars IC
S
Dimensions Tough 1 Hard
Designation IC S RE IC28 IC328 IC250 IC350 IC908 IC520M
XOMT 060204-DT 6.16 2.56 0.40 • • • • • •
• Two cutting edges • For hard materials and interrupted cut
For tools, see pages: A-SXFOR-DR (120) • A-SXFOR/L (119)
200 ISCAR
