PARTING TGTR/L-JHP-MC WF CWN-CWX LH HBH Coolant B H WB OAH Bar Max
HF
Parting and Grooving Toolholders
with Bottom Inlets for
inlet
High-Pressure Coolant
OAL
Carrying TANG-GRIP Inserts

Left-hand shown
Designation CWN (1) CWX (2) H B HF WB OAL OAH LH HBH CUTDIA (3) Insert
TGTR/L 2020-D42-2-JHP-MC 1.80 2.50 20.0 20.0 20.0 1.72 99.00 25.70 29.0 - 42.0 TAG 2
TGTR/L 2020-D65-3-JHP-MC 2.80 3.50 20.0 20.0 20.1 2.50 110.50 37.60 40.5 10.0 65.0 TAG 3
TGTR/L 2020-D82-3-JHP-MC 2.80 3.50 20.0 20.0 20.1 2.50 119.00 38.80 49.0 10.0 82.0 TAG 3
TGTR/L 2525-D65-3-JHP-MC 2.80 3.50 25.0 25.0 25.1 2.50 126.00 37.60 41.0 5.0 65.0 TAG 3
TGTR/L 2525-D82-3-JHP-MC 2.80 3.50 25.0 25.0 25.1 2.50 134.50 38.80 49.5 5.0 82.0 TAG 3
• For user guide and accessories, see pages 538-547
(1) Minimum cutting width
(2) Maximum cutting width
(3) Maximum cutting diameter
For inserts, see pages: TAG N-A (510) • TAG N-C/W/M (506) • TAG N-HF (506) • TAG N-J/JS/JT (508) • TAG N-LF (509) • TAG N-MF (507)
• TAG N-UT (510) • TAG R/L-C (507) • TAG R/L-J/JS (509)

Spare Parts
Designation
TGTR/L 2020-D42-2-JHP-MC ETG 2*
TGTR/L 2020-D65-3-JHP-MC ETG 3-4-SH*
TGTR/L 2020-D82-3-JHP-MC ETG 3-4-SH*
TGTR/L 2525-D65-3-JHP-MC ETG 3-4-SH*
TGTR/L 2525-D82-3-JHP-MC ETG 3-4-SH*
* Optional, should be ordered separately

CUTDIA CUTDIA

TGTR/L-2T..SH-L120 OAL
Integral Shank Short-Head H HF
TANG-GRIP Toolholders for HBH
Parting and Grooving HBL TGTR/L 10
B WB CWN-CWX
CDX 10.8 Right-hand shown
Designation CWN (1) CWX (2) H HF B WB OAL HBL HBH CDX (3) CUTDIA (4)
TGTR/L 1010-2T10SH-L120-IQ 1.80 2.50 10.0 10.1 10.0 1.65 120.00 15.0 5.0 10.00 26.0
TGTR/L 1212-2T15SH-L120-IQ 1.80 2.50 12.0 12.1 12.0 1.65 120.00 15.0 3.0 15.00 30.0
TGTR/L 1616-2T18SH-L120-IQ 1.80 2.50 16.0 16.1 16.0 1.65 120.00 - - 18.00 36.0
• For user guide, see pages 538-547
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
(4) For parting
* Optional, should be ordered separately
For inserts, see pages: TAG N-A (510) • TAG N-C/W/M (506) • TAG N-J/JS/JT (508) • TAG N-LF (509) • TAG N-MF (507) • TAG N-UT (510)
• TAG R/L-C (507) • TAG R/L-J/JS (509)
