FACE MILLS T290 FLN-10 DCONMS APMX OAL
DHUB
90° Face Mills Carrying T290
LNMT 1004... Tangentially
Clamped Inserts
DC

DC
OAL
Designation
T290 FLN D32-05-16-10
0.09
A
5
9.00
16.00
30.00
T290 FLN D40-06-16-10 32.00 CICT (1) APMX 35.00 DHUB DCONMS Arbor (2) kg
6
9.00
40.00
35.00
0.16
16.00
A
34.00
T290 FLN D50-07-22-10 50.00 7 9.00 40.00 46.00 22.00 A 0.29
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: T290 LNMT/LNHT 1004 (474)
Spare Parts
Designation
T290 FLN D32-05-16-10 SR 10504970 BLD IP15/M7 SW6-T-SH SR M8X20DIN912
T290 FLN D40-06-16-10 SR 10504970 BLD IP15/M7 SW6-T-SH SR M8X20DIN912
T290 FLN D50-07-22-10 SR 10504970 BLD IP15/M7 SW6-T-SH SR M10X25 DIN912

DHUB

F90SP-10 DCONMS
90° Face Mills Carrying S/X/
QPMT 1004... Inserts OAL
APMX
DC

Designation DC (1) CICT (2) APMX OAL DHUB DCONMS Arbor (3) kg
F90SP D 40-04-16-10 40.00 4 9.60 40.00 38.00 16.00 A 0.42
F90SP D 50-04-22-10 50.00 4 9.60 40.00 48.00 22.00 A 0.37
F90SP D 50-06-22-10 50.00 6 9.60 40.00 48.00 22.00 A 0.39
F90SP D 63-06-22-10 63.00 6 9.60 40.00 48.00 22.00 A 0.48
F90SP D 63-07-22-10 63.00 7 9.60 40.00 48.00 22.00 A 0.42
F90SP D 80-06-27-10 80.00 6 9.60 50.00 60.00 27.00 B 0.88
F90SP D 80-09-27-10 80.00 9 9.60 50.00 60.00 27.00 B 1.50
• For user guide, see pages 542-547
(1) D is 0.2 mm larger when QPMT inserts are used
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: QPMR 1004-HQ-M (495) • QPMT 100408PDTN (495) • SPCT/SPMR PDR (496) • SPMT-HQ (495) • XPMT-HQ (496)

Spare Parts
Designation
F90SP D 40-04-16-10 SR 10514114 SW6-T-SH BLD IP15/M7 SR M8X30DIN912
F90SP D 50-04-22-10 SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 50-06-22-10 SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 63-06-22-10 SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 63-07-22-10 SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 80-06-27-10 SR 10514114 SW6-T-SH BLD IP15/M7
F90SP D 80-09-27-10 SR 10514114 SW6-T-SH BLD IP15/M7
